S 415 NF 3-TUERER - 628.788 - 71 PARTITION PANELS

Поз.
Артикул
Описание
121
A6288150011
PLATE
124
A6288150714
BRACKET
127
N914112008032
SCREW COVER TO AXLE HOUSING
175
A3577110043
MOUNTING
180
A6669900040
WASHER
185
A0019909920
SCREWM6X12 TX30
190
A0009901129
SCREWM 8X22, T40
195
N913023008006
NUT SHAFT TO THROTTLE VALVE, 401-403 , 421-423 , 441-443550204 407 , 409 , 427 , 429 , 44739905 404 , 424 , 44411324
240
A6288151365
PAD
250
A3068150262
LEDGE LEFT AND RIGHT
310
A6288155153
GRIP RAIL
310
A3578158455
GRIP RAIL
330
A3118101155
GRIP RAIL , .......INO.7E86I.......I.......I II
500
A6288150214
BRACKET
505
A6288150314
BRACKET GRIP RAIL MOUNTING, STATE COLOR WHEN ORDERING STATE IDENT NO. WHEN ORDERING
510
A6288150414
BRACKET , .......I.......INO.7E87I.......I II
