Поз.
Артикул
Описание
44
HOSE ,D 209702
47
HOSE
50
MOLDED HOSE ARC REDUCED 90 DEGREES 70/60MM
68
68
HOSE10X19X100MM
71
MOLDED HOSE ARC REDUCED 90 DEGREES 15/10MM
77
86
CLAMP HOSE TO FITTING 11 - 20 MM
89
CLAMP HOSE TO RADIATOR AND TO EXPANSION TANK 12-22X13 MM
92
CLAMP HOSE TO INTAKE PIPE 35-50X13MM
95
CLAMP CONNECTION OF COOLING WATER LINES 55-75X13MM
98
CLAMP HOSE TO RADIATOR,PIPE ELBOW,AND WATER PUMP 60-80X13 MM
101
CLAMP
104
SCREW BRACKET AND CLAMP M6X20
107
SCREW BRACKET TO CAB REAR PANEL M 8X20
110
SCREW , Replaced By: N910143008002
113
HEXAGON HEAD BOLT. SCREW BRACKET TO SIDE MEMBER M8X35
119
HEXAGON HEAD BOLT RESONATOR TO TRANSMISSION CASE,K 138633
128
HEXAGON HEAD BOLT HEAT SHIELD MOUNTING M16X1.5X30
128
SCREW FRONT SPRINGS TO FRONT AXLE
143
CLAMP , Replaced By: N916016010211
143
CLAMP LINE MOUNTING 10/15, Replaced By: N000000007511
146
CLAMP60/25MM, Replaced By: N000000006126
146
CLAMP60/25RSGU
149
BANJO UNION10/14
149
BANJO UNION10/14MM
152
HOLLOW SCREW
152
SCREW
158
SCREW PLUG FUEL TANK
158
SCREW PLUG, FILLINGM14X1,5
161
SEALING RING. SEAL RING ENGINE BREATHING
197
ADAPTOR SOCKETS
221
HOSE60 X 72 X 100 MM, TO BE ADAPTED DURING ASSEMBLY
221
HOSE RETURN, FROM RETARDER TO ENGINE
221
HOSE COOLING WATER LINE TO COOLING WATER LINE
221
HOSE RETURN, FROM RETARDER TO ENGINE, Replaced By: N000000005010
290
293
296
308
311
314
CLAMP BRAKE HOSE BRACKET
314
CLAMP LINE MOUNTING 15-18 MM,V 207570
317
CLAMP , Replaced By: A3829950701
317
CLAMP LINE MOUNTING
323
326
BRACKET
329
332
BRACKET
335
BRACKET
344
347
350
MOLDED HOSE FROM HEATING WATER PIPE TO HEATER
353
HOSE NARROWED STRAIGHT SURFACE 70/60MM
359
SCREW , Replaced By: N910143008000
373
383
MOLDED HOSE ARC REDUCED 90 DEGREES 65/60MM, Replaced By: A0025012082
383
HOSE. RADIATOR HOSE ARC REDUCED 90 DEGREES 65/60MM, Replaced By: A0015013982
386
HEXAGON HEAD BOLT. SCREWM 12X1,5X20 MM - TO A 202 490 08 41
389
NUT , Replaced By: N913023006001
392
HEXAGON NUT. NUT BRACKET TO CAB REAR PANEL
395
NUT , Replaced By: N913023010002
398
GROMMET
402
408
413
418
423
428
