Поз.
Артикул
Описание
11
PLASTIC PIPE10X13MM, ORDER BY THE METER
41
CLAMP LINE MOUNTING 10/15, Replaced By: N000000007511
41
CLAMP
41
CLAMP , Replaced By: N916016010211
41
CLAMP DELIVERY AND SUCTION LINES TO ENGINE, FRONT
41
CLAMP10/15
41
CLAMP SUCTION/DELIVERY/RETURN LINES 12/15MM
41
CLAMP ,K 147121, Replaced By: N000000000319
44
SCREW BRACKET AND CLAMP M6X20
44
HEXALOBULAR BOLT BRACKET TO BRACKET M8X16
44
SCREW , Replaced By: N914146006102
47
NUT , Replaced By: N913023006001
53
HOLLOW SCREW FITTING AIR RESERVOIR,CONNECTION: "21",5 181510
83
VALVE
92
FITTING
92
FITTING
95
FITTING
98
BANJO BOLT
98
HOLLOW SCREW LINE CONNECTION TO TRANSMISSION
98
SCREW
101
SEALING RING. SEAL RING DELIVERY LINE TO STEERING
101
SEAL RINGTO 000 553 03 05,000 553 18 05,
101
SEALING RING. SEAL RING ENGINE BREATHING
101
SEAL RING PNEUMATIC VALVE
104
FITTING ADJUSTABLE 60 DEGREES, FROM IDENT NO. 081149 ALSO INSTALLED ON 079775
146
SHUT-OFF VALVE
152
T-FITTING ,WEB 444203 23 000024
167
LOCK. NUT , Replaced By: A0039941745
193
CONNECTOR
196
BANJO UNION10/14MM
196
199
CONNECTORM16X1,5
