Поз.
Артикул
Описание
32
BRACKET SPARE WHEEL MOUNTING,5 962476
32
CONSOLE SPARE WHEEL MOUNTING,LEFT,K 038556
32
CONSOLE SPARE WHEEL MOUNTING,LEFT
32
CONSOLE SPARE WHEEL MOUNTING,LEFT,K 038556
32
BRACKET LEFT
32
BRACKET LEFT
36
BEARING BRACKET AT BRACKET
38
SUPPORT AT BRACKET
40
PLATE AT BRACKET
90
SCREW CONSOLE TO SIDE MEMBER
90
SCREW REAR EXHAUST PIPE TO MUFFLER
90
SCREW END PIECE TO EXHAUST PIPE M 10X25
100
SCREW CONSOLE TO SIDE MEMBER
110
NUT SUPPORT TO SIDE MEMBER
120
NUT SUPPORT TO SIDE MEMBER
120
NUT STRAP TO BRACKET
120
NUT , Replaced By: N910113010000
130
CONSOLE SPARE WHEEL MOUNTING,RIGHT
130
BRACKET RIGHT
130
BRACKET RIGHT
130
BRACKET SPARE WHEEL MOUNTING,5 962476
130
BRACKET RIGHT
130
CONSOLE SPARE WHEEL MOUNTING,RIGHT,K 038556
130
BRACKET SPARE WHEEL MOUNTING,LEFT,5 962476
140
SUPPORT AT BRACKET
150
BRACKET AT BRACKET
150
BRACKET SPARE WHEEL CARRIER
160
SCREW CONSOLE TO SIDE MEMBER
160
SCREW , Replaced By: N308676012026
160
SCREW AIR CLEANER SUPPORT TO SIDE MEMBER, REAR
160
SCREW DELIVERY AND SUCTION LINES TO FRAME M 12X35
180
NUT SUPPORT TO SIDE MEMBER
190
SHIM BRACKET TO FRAME
200
BASE LEFT AND RIGHT CONSOLES TO FRAME
210
SCREW BRACKET TO SIDE MEMBER
210
SCREW AT CROSS MEMBER
210
SCREW BRACKET TO REAR SPRING SADDLE COUNTER PLATE
210
SCREW BRACKET TO CAB CONSOLE,K 035197
210
SCREW LEFT AND RIGHT CONSOLES TO FRAME M 14X60
210
SCREW , Replaced By: N000961014064
210
SCREW BRACKET TO CAB CONSOLE M14X1.5X40
220
WASHER SPARE WHEEL CARRIER
220
WASHER UNDERRUN PROTECTION AND BRACKET TO FRAME
230
NUT BRACKET TO SIDE MEMBER
230
NUT , Replaced By: N910113014001
240
SCREW , Replaced By: N308676012026
240
SCREW CONSOLE TO SIDE MEMBER
240
SCREW DELIVERY AND SUCTION LINES TO FRAME M 12X35
250
NUT SUPPORT TO SIDE MEMBER
280
BRACKET SPARE WHEEL CARRIER
290
CLAMPING PIECE SPARE WHEEL CARRIER
300
SCREW BRACKET TO SIDE MEMBER
300
SCREW STEERING SUPPORT TO FRAME M 14X50
300
SCREW , Replaced By: N000961014064
305
LOCK WASHER BRACKET TO SIDE MEMBER,5 703114
330
SCREW BRACKET TO SIDE MEMBER M 14X1.5X35
330
SCREW , Replaced By: N308676014020
330
SCREW FRONT SPRING REAR BRACKET TO CROSS MEMBER
340
ANGLE
350
BEARING BRACKET
360
SCREW SUPPORT TO CROSS MEMBER M 10X28
360
SCREW END PIECE TO EXHAUST PIPE M 10X25
360
HEXAGON HEAD BOLT. SCREW BRACKET TO SIDE MEMBERM 12X1.5X30
370
WASHER RADIATOR TO RUBBER MOUNTING
370
WASHER STRUT TO CROSS MEMBER
370
WASHER , Replaced By: N000125010532
370
WASHER , Replaced By: N007349010007
380
NUT , Replaced By: N910113010000
380
NUT , Replaced By: N910113012003
380
NUT STRAP TO BRACKET
380
HEXAGON NUT EXHAUST PIPE TO BRACKET ON SIDE MEMBER
999
ANGLE AIR RESERVOIR
