Поз.
Артикул
Описание
120
TANK COOLING WATER EXPANSION
120
TANK COOLING WATER EXPANSION
123
RADIATOR CAP , Replaced By: A0005016415
123
RADIATOR CAP FILLER NECK
126
SEAL RING
129
RADIATOR CAP
132
RADIATOR CAP CENTRAL
132
RADIATOR CAP CENTRAL
135
GASKET O.D., 52 MM
138
GASKET O.D., 37 MM
141
DRAIN PIPE
144
SENDER UNIT COOLING WATER LEVEL INDICATOR
147
MOUNTING PLATE FROM EXPANSION TANK TO RADIATOR
147
BRACKET. LOCK , Replaced By: A6525040038
150
HOSE , Replaced By: A6565010382
150
HOSE FROM EXPANSION TANK TO ENGINE
153
CLAMP , Replaced By: N916017011001
153
CLAMP HOSE TO RADIATOR AND TO EXPANSION TANK 12-22X13 MM
156
PLATE FROM EXPANSION TANK TO RADIATOR 40X40 MM
156
PLATE FROM EXPANSION TANK TO RADIATOR
159
LINE FROM RADIATOR TO THERMOSTAT
165
HOSE FROM RADIATOR TO THERMOSTAT
165
HOSE , Replaced By: A6555015582
165
HOSE FROM RADIATOR TO THERMOSTAT
165
HOSE FROM RADIATOR TO THERMOSTAT
165
HOSE FROM RADIATOR TO THERMOSTAT
165
HOSE FROM RADIATOR TO THERMOSTAT
165
HOSE FROM RADIATOR TO THERMOSTAT
165
HOSE FROM RADIATOR TO THERMOSTAT, TO BE ADAPTED DURING ASSEMBLY
165
HOSE FROM RADIATOR TO THERMOSTAT, TO BE ADAPTED DURING ASSEMBLY
165
HOSE FROM RADIATOR TO THERMOSTAT
165
HOSE FROM RADIATOR TO THERMOSTAT
168
CLAMP HOSE 70-90X13 MM
168
CLAMP , Replaced By: N000000000674
171
HOSE FROM RADIATOR OUTLET TO WATER PUMP, ORDER BY THE METER
171
HOSE FROM RADIATOR OUTLET TO WATER PUMP
171
HOSE FROM RADIATOR OUTLET TO WATER PUMP
171
HOSE FROM RADIATOR OUTLET TO WATER PUMP
171
HOSE FROM RADIATOR OUTLET TO WATER PUMP
174
PIPE ELBOW FOR SCREW FITTING
174
LINE FROM RADIATOR OUTLET TO WATER PUMP
174
PIPE ELBOW FOR SCREW FITTING
174
PIPE ELBOW FOR SCREW FITTING
177
PIPE ELBOW FROM RADIATOR OUTLET TO WATER PUMP
177
PIPE ELBOW FROM RADIATOR OUTLET TO WATER PUMP
177
PIPE ELBOW AT WATER PUMP,5 510518
180
PIN PIPE ELBOW TO BRACKET,K 023462
183
SPACER RING PIPE ELBOW TO BRACKET,K 023462
183
WASHER , Replaced By: A1894660751
186
SCREW END PIECE TO EXHAUST PIPE M 10X25
186
SCREW END PIECE TO EXHAUST PIPE M 10X25
186
SCREW STRAP TO BRACKET
189
LINE FROM RADIATOR OUTLET TO WATER PUMP
189
PIPE ELBOW FROM RADIATOR OUTLET TO WATER PUMP
192
HOSE FROM RADIATOR OUTLET TO WATER PUMP, ORDER BY THE METER
195
CLAMP HOSE 70-90X13 MM
195
CLAMP , Replaced By: N000000000674
198
BRACKET CONNECTOR
201
CONNECTOR FOR SCREW FITTING
201
CONNECTOR , Replaced By: A6205010323
207
GASKET , Replaced By: A4422010480
207
GASKET CONNECTOR
207
GASKET CONNECTOR, Replaced By: A0002011280
207
GASKET CONNECTOR, Replaced By: A0002011180
207
GASKET CONNECTOR, Replaced By: A0002011080
999
LINE GAS LINE 10X1,5, LENGTH AVAILABLE 3000 MM REPAIR WORK SUBJECT TO SAFETY CHECK
999
CLAMP FROM AIR CLEANER TO TRANSVERSE INTAKE PIPE 100-120X13 MM
999
LINE FEED AND RETURN LINES TO HEATING
999
COOLING WATER PIPE FEED
999
COOLING WATER PIPE CONNECTION OF COOLING WATER LINES
999
LINE RETURN LINE TO RADIATOR
999
BRACKET LINE MOUNTING
999
COOLING WATER PIPE RETURN LINE TO RADIATOR
999
COOLING WATER PIPE FEED TO RADIATOR
999
HOSE FROM RADIATOR TO WATER PUMP
999
BRACKET CHARGING AIR INTERCOOLER,RIGHT TOP
999
PIPE ELBOW FOR SCREW FITTING
999
HOSE , Replaced By: A6565012482
999
BRACKET CHARGING AIR INTERCOOLER TO RADIATOR
999
PIPE ELBOW FROM CHARGING AIR INTERCOOLER TO ENGINE
999
HOSE FEED, OIL COOLER
999
HOSE RETURN, OIL COOLER,K 131866
999
HOSE FROM RADIATOR OUTLET TO WATER PUMP
999
HOSE CONNECTION OF COOLING WATER LINES
999
HOSE COOLING WATER LINE
999
MOUNTING RAIL SEALING LIP TO RADIATOR
999
BREATHER PIPE FROM ENGINE TO EXPANSION TANK
999
BRACKET FEED LINE TO ENGINE
999
BREATHER PIPE DE-AERATION, FROM RADIATOR TO SEPARATION POINT
999
CLAMP , Replaced By: A0059970690
