Поз.
Артикул
Описание
5
INSULATING HOSE HOSE LINE PROTECTION 10 MM, ORDER BY THE METER
8
INSULATING HOSE ELECTRIC CABLE THRU FRAME
8
INSULATING HOSE ELECTRIC CABLE THRU FRAME
8
INSULATING HOSE ELECTRIC CABLE THRU FRAME
8
INSULATING HOSE ELECTRIC CABLE THRU FRAME
8
INSULATING HOSE ELECTRIC CABLE THRU FRAME
8
INSULATING HOSE ELECTRIC CABLE THRU FRAME
11
BRACKET AT ENGINE,REAR
17
BRACKET LINE TO FRONT PANEL
20
BRACKET RIGHT COMPRESSED AIR LINES
20
BRACKET LEFT COMPRESSED AIR LINES
23
BRACKET ACCORDION TUBE
23
BRACKET ACCORDION TUBE
26
SEAL ELECTRIC CABLE THRU CAB FLOOR
29
BRACKET ELECTRIC CABLE THRU CAB FLOOR
32
SEAL RING ELECTRIC CABLE THRU CAB FLOOR
35
LOCK ELECTRIC CABLE THRU CAB FLOOR
38
SHEET METAL SCREW ELECTRIC CABLE THRU CAB FLOOR
41
WASHER , Replaced By: N009021005205
41
WASHER CABLE CONNECTOR TO BRACKET AND TO FRAME,RESP.
999
BRACKET ACCORDION TUBE
999
BRACKET ACCORDION TUBE
