Поз.
Артикул
Описание
5
PUMP (HAND PUMP) POWER PACKER
5
PUMP (HAND PUMP) WEBER
8
PUMP (HAND PUMP) WEBER
8
PUMP (HAND PUMP), FOR COMPONENT PARTS SEE SPARE PARTS LIST
11
PISTONTO 000 553 79 01,WEBER
11
PISTONTO 000 553 89 01
14
VALVETO 000 553 89 01
14
VALVETO 000 553 79 01,WEBER
17
FILTER
20
FITTED WASHER
23
LOCK RING
26
SCREW
26
SCREWTO 000 553 65 01,000 553 69 01,
29
SCREW
29
SCREW , Replaced By: N000000000190
32
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
35
GASKET KIT HAND PUMP
38
REPAIR KIT HAND PUMP TO 000 553 65 01,000 553 69 01,
41
SCREW BRACKET TO SIDE MEMBER
41
SCREW , Replaced By: N304017010002
44
NUT , Replaced By: N910113010000
44
NUT STRAP TO BRACKET
47
BRACKET HAND PUMP
50
SCREW BRACKET TO SIDE MEMBER M 14X1.5X35
50
SCREW , Replaced By: N308676014020
50
SCREW BRACKET TO CAB CONSOLE M14X1.5X40
53
NUT BRACKET TO SIDE MEMBER
53
NUT , Replaced By: N910113014001
95
CYLINDER , Replaced By: A0015533505
95
CYLINDER HYDRAULIC SYSTEM USED FOR CAB TILTING WEBER
98
GUIDEWEBER
101
FITTINGWEBER,TO 001 553 35 05
104
GASKET KIT HYDRAULIC CYLINDER WEBER
107
BEARING BRACKET HYDRAULIC CYLINDER
110
SCREW BEARING BRACKET TO FRAME M 14X20, MODEL 415/416/417 FOR USE WITH SHORT CAB MERCEDES BENZ
110
SCREW , Replaced By: N308676016006
110
SCREW STEERING BOX ASSEMBLY TO STEERING SUPPORT
113
NUT , Replaced By: N910113016001
113
NUT CONSOLE TO SUPPORT
116
BUSHING HYDRAULIC CYLINDER TO BEARING BRACKET
119
WASHER HYDRAULIC CYLINDER TO CAB
122
COTTER PIN6,3X36 MM
125
WASHER HYDRAULIC CYLINDER TO CAB
128
WASHER HYDRAULIC CYLINDER TO CAB
131
WASHER HYDRAULIC CYLINDER TO CAB
134
NUT COMBINATION CYLINDER TO BEARING BRACKET, Replaced By: N910113016002
134
NUT COMBINATION CYLINDER TO BEARING BRACKET
