Поз.
Артикул
Описание
5
VALVE (SAFETY VALVE) WABCO 10 BAR
8
T-FITTING LINE CONNECTION
11
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940203
11
THRUST RING CHECK VALVE TO AIR RESERVOIR
14
O-RING CHECK VALVE TO AIR RESERVOIR
17
NUT CHECK VALVE TO AIR RESERVOIR
20
TRAVEL SENSOR REAR AXLE,K 186868
23
LEVER TRAVEL SENSOR
24
LEVER TRAVEL SENSOR,K 186868
24
LEVER RIGHT
24
LEVER LEFT
25
BALL STUD. BALL PIVOT TOP B10X4,5 MM
25
BALL PIVOT
26
BRACKET AIR SPRING VALVE
27
BRACKET TRAVEL SENSOR TO FRAME SIDE MEMBER
29
BALL JOINT TRAVEL SENSOR
29
ROD , Replaced By: A0003290930, +001A0003291030, +001N304032008006, +001N304032008007, +001N900331008427
29
ROD , Replaced By: A0003290930, +001A0003291030, +001N304032008006, +001N304032008007, +001N900331008427
29
ROD , Replaced By: A0003290930, +001A0003291030, +001N304032008006, +001N304032008007, +001N900331008427
29
ROD , Replaced By: A0003290930, +001A0003291030, +001N304032008006, +001N304032008007, +001N900331008427
30
VALVE REAR AXLE SELF-LEVELLING DEVICE
31
MAGNET ,5 760168K 154651
32
PROTECTIVE CAPWABCO
33
AIR CLEANER ,5 760168K 154651
34
REPAIR KITTO 388 997 88 36
36
SOLENOID VALVE SELF-LEVELLING DEVICE,K 186868
36
SOLENOID VALVE WITH VEHICLES: 6X2, 6X2/4
37
MAGNET
37
MAGNET ,K 186868
38
MUFFLER TRAILER CONTROL VALVE
38
MUFFLER , Replaced By: A0004302370
39
REPAIR KIT (SOLENOID VALVE),K 186868
39
REPAIR KIT SOLENOID VALVE
39
REPAIR KIT ,5 760168K 154651
40
SCREW. UNION SCREW LINE CONNECTION
41
LOCK COMPRESSED-AIR-LINE PLUG-CONNECTION
44
SEAL RING COMPRESSED-AIR-LINE PLUG-CONNECTION
47
BRACKET AIR SPRING VALVE
48
BRACKET AIR SPRING VALVE
49
BRACKET SOLENOID VALVE,K 186868
104
BRACKET OVERFLOW VALVE
999
BALL JOINT LEFT-HAND THREAD,BALL DIAMETER 10 MM
999
REPAIR KITTO 001 429 52 44
999
VALVE
999
NUT
999
NUT BALL SOCKET TO ROD
999
PULL ROD PNEUMATIC SUSPENSION CONTROL
