Поз.
Артикул
Описание
5
CROSS MEMBER IN FRAME BEND, TO BE ADAPTED DURING ASSEMBLY
5
CROSS MEMBER , THE OLD PART MUST NO LONGER BE INSTALLED IN THIS PLACE, Replaced By: A6763100037, +001A6753110460, +001A6753110560
14
REINFORCEMENT LEFT AND RIGHT BOTTOM
14
REINFORCEMENT , Replaced By: A6753110860
14
REINFORCEMENT , Replaced By: A6753110860
32
CONSOLE BODY MOUNTING
35
CONSOLE
38
BEARING SHACKLE TO FRAME
41
CROSS MEMBERNO.5
50
PLATE AT SIDE MEMBER
53
CROSS MEMBER REAR-SPRING REAR BRACKET NO.6
83
CONSOLE BODY MOUNTING
89
CROSS MEMBER (REAR CROSS MEMBER)
92
SCREW BRACKET TO SIDE MEMBER M 14X1.5X35
92
SCREW , Replaced By: N308676014020
95
NUT BRACKET TO SIDE MEMBER
95
NUT , Replaced By: N910113014001
98
CONSOLE BODY MOUNTING
101
SCREW BRACKET TO SIDE MEMBER
101
SCREW , Replaced By: N304017010002
104
WASHER RADIATOR TO RUBBER MOUNTING
104
WASHER , Replaced By: N000125010532
107
NUT STRAP TO BRACKET
107
NUT , Replaced By: N910113010000
999
WASHER BRACKET TO FRAME
999
SCREW BRACKET TO LEFT SIDE MEMBER
999
NUT FRONT SPRING FRONT BRACKET TO SIDE MEMBER
