Поз.
Артикул
Описание
5
HOSE , ORDER BY THE METER
8
SPACER TUBE
11
CLAMP. LOOM TIE
11
LOOM TIE BRAKE HOSE FIXTURE
11
LOOM TIE
11
LOOM TIE
11
LOOM TIE4X14-3/4
14
SCREW HAND BRAKE VALVE 1/4-20
17
SCREW5/16-18,MAO 10055/02
17
SCREW CABLE MOUNTING 1/4-20
17
HEXAGON HEAD BOLT. SCREW CLUTCH TO FLYWHEEL M8X16 MM
17
PART NAME MISSING SCREW
20
WASHER BRACKET MOUNTING 1/4
20
WASHER VALVE TO BRACKET 5/16-.640
32
NUT STARTING MOTOR 5/6-24
32
NUT STARTING MOTOR 10-32
32
NUT COMPRESSED AIR LINE TO CROSS MEMBER1/4,M 033721
32
PART NAME MISSING NUT
35
BRACKET
38
CLAMP ,K 147121, Replaced By: N000000000319
38
CLAMP
38
CLAMP COMPRESSED AIR LINE TO BRACKET
38
CLAMP , Replaced By: QT01-27263-000
38
CLAMP
