Поз.
Артикул
Описание
3
BRAKE VALVE SERVICE BRAKE WABCO
3
BRAKE VALVE SERVICE BRAKE KNORR
9
LOCKTO 345 431 70 05
12
SPRINGTO 345 431 71 05
12
SPRINGTO 345 431 70 05
12
SPRINGTO 345 431 70 05
21
PISTONTO 345 431 70 05
21
PISTONTO 345 431 71 05
27
LOCK RING PLANETARY CARRIER
27
LOCK RINGTO 345 431 71 05
27
LOCK RINGTO 345 431 71 05
27
LOCK RING
39
REPAIR KIT LARGE SCOPE TO 345 431 70 05
39
REPAIR KIT SMALL SCOPE TO 345 431 70 05
39
REPAIR KIT , Replaced By: A0014300460
39
REPAIR KIT SMALL SCOPE TO 345 431 71 05
42
GASKET BRAKE SHOE WITH LINING
45
SPRING WASHER BRAKE SHOE WITH LINING
48
NUT BATTERY CASE
51
HOLLOW SCREW FRONT AXLE REGULATING SOLENOID VALVE, CONNECTION: "10",K 009079
54
HOLLOW SCREW FOUR-CIRCUIT PROTECTIVE VALVE, CONNECTION: "24"
63
SCREW PLUG
66
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
69
VALVE , Replaced By: A6934297144
69
VALVE (QUICK BREATHER VALVE) VARGA
72
REPAIR KITTOA 382 429 70 44, A 693 429 71 44
72
REPAIR KITTO A 364 429 70 44
75
HOLLOW SCREW FRONT AXLE REGULATING SOLENOID VALVE, CONNECTION: "10",K 009079
78
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
81
SCREW PLUG
86
SCREW-IN FITTING OIL LINE CONNECTION
96
BRACKET QUICK-RELEASE VALVE
99
BOLT. SCREW QUICK-RELEASE VALVE TO BRACKET
102
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
105
VALVE (RELAY VALVE) KNORR
105
VALVE (RELAY VALVE),REAR AXLE
108
REPAIR KITTO 003 429 30 44,KNORR
108
REPAIR KITKNORR
111
FITTING REAR AXLE REGULATING SOLENOID VALVE, CONNECTIONS: "10"
114
SEAL RING LOAD/NO-LOAD VALVE,CONNECTIONS: "20,21",5 727400
117
HOLLOW SCREW FRONT AXLE REGULATING SOLENOID VALVE, CONNECTION: "10",K 009079
120
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
124
FITTING LOCKING VALVE,CONNECTION: "2"
126
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
129
THRUST RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
129
THRUST RING LOCKING VALVE
132
NUT LOCKING VALVE TO TRAILER CONTROL VALVE,CONNECTION: "42"
135
SCREW PLUG
138
BRACKET REAR AXLE RELAY VALVE
141
WASHER TRAILER PLUG SOCKET TO BRACKET
144
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
147
SCREW BRACKET TO SIDE MEMBER M10X30
150
NUT BRACKET TO SIDE MEMBER,XB209706
153
VALVE (TRAILER CONTROL VALVE) "KNORR"
153
VALVE TWO-WAY
153
VALVE (TRAILER CONTROL VALVE) "KNORR"
156
HOLLOW SCREW FRONT AXLE REGULATING SOLENOID VALVE, CONNECTION: "10",K 009079
159
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
162
T-FITTING DIAPHRAGM CYLINDER,CONNECTION: "11",5 272559
165
SWITCH SUPPLY PRESSURE,5 966147
168
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
171
THRUST RING LOCKING VALVE TO TRAILER CONTROL VALVE,CONNECTION: "42"
171
THRUST RING LOCKING VALVE
171
THRUST RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
174
NUT LOCKING VALVE TO TRAILER CONTROL VALVE,CONNECTION: "42"
