Поз.
Артикул
Описание
3
BRAKE VALVE SERVICE BRAKE KNORR
3
BRAKE VALVE SERVICE BRAKE WABCO
9
SPRINGTO 345 431 70 05
9
SPRINGTO 345 431 70 05
9
SPRINGTO 345 431 71 05
18
PISTONTO 345 431 71 05
18
PISTONTO 345 431 70 05
24
LOCK RINGTO 345 431 71 05
24
LOCKTO 345 431 70 05
27
LOCK RINGTO 345 431 71 05
30
LOCK RING
33
LOCK RING PLANETARY CARRIER
36
REPAIR KIT SMALL SCOPE TO 345 431 71 05
36
REPAIR KIT , Replaced By: A0014300460
36
REPAIR KIT SMALL SCOPE TO 345 431 70 05
36
REPAIR KIT LARGE SCOPE TO 345 431 70 05
39
GASKET BRAKE SHOE WITH LINING
42
SPRING WASHER BRAKE SHOE WITH LINING
45
NUT BATTERY CASE
48
HOLLOW SCREW FRONT AXLE REGULATING SOLENOID VALVE, CONNECTION: "10",K 009079
51
HOLLOW SCREW FOUR-CIRCUIT PROTECTIVE VALVE, CONNECTION: "24"
54
HOLLOW SCREW FITTING LEFT AND RIGHT COMBINATION CYLINDERS, CONNECTION: "11,12",5 356525
60
SCREW PLUG
63
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
69
VALVE , Replaced By: A6934297144
69
VALVE (QUICK BREATHER VALVE) VARGA
72
REPAIR KITTO A 364 429 70 44
72
REPAIR KITTOA 382 429 70 44, A 693 429 71 44
75
HOLLOW SCREW FRONT AXLE REGULATING SOLENOID VALVE, CONNECTION: "10",K 009079
78
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
81
SCREW PLUG
84
ELBOW FITTING DIAPHRAGM CYLINDER,CONNECTION: "1,11"
87
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
90
THRUST RING LOCKING VALVE
90
THRUST RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
93
NUT LOAD/NO-LOAD VALVE,CONNECTIONS: "10,20"
96
BRACKET QUICK-RELEASE VALVE
99
BOLT. SCREW QUICK-RELEASE VALVE TO BRACKET
102
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
108
HOLLOW SCREW FITTING SERVICE BRAKE VALVE,CONNECTION: "12"
111
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
135
VALVE (RELAY VALVE)
135
VALVE (RELAY VALVE) KNORR
135
VALVE (RELAY VALVE),REAR AXLE
138
REPAIR KITKNORR
138
REPAIR KITTO 003 429 30 44,KNORR
138
REPAIR KITTO 386 429 70 44
141
FITTING REAR AXLE REGULATING SOLENOID VALVE, CONNECTIONS: "10"
144
FITTING FRONT AXLE REGULATING SOLENOID VALVE, CONNECTION: "20", Replaced By: N000000006191
144
FITTING , Replaced By: A0029971172
147
FITTING TEST VALVE TO RELAY VALVE,CONNECTION: "40"
150
SEAL RING LOAD/NO-LOAD VALVE,CONNECTIONS: "20,21",5 727400
153
HOLLOW SCREW FRONT AXLE REGULATING SOLENOID VALVE, CONNECTION: "10",K 009079
156
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
162
SCREW-IN FITTING OIL LINE CONNECTION
162
CONNECTION FITTING , Replaced By: A0049971772
180
SCREW PLUG
186
BRACKET , Replaced By: A3184280240
192
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
201
VALVE (TRAILER CONTROL VALVE) "KNORR"
201
VALVE TWO-WAY
201
VALVE (TRAILER CONTROL VALVE) "KNORR"
210
T-FITTING AIR RESERVOIR,CONNECTION: "31"
216
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
219
THRUST RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
222
NUT LOAD/NO-LOAD VALVE,CONNECTIONS: "10,20"
