Поз.
Артикул
Описание
5
PANELLING , Replaced By: A9016307607
5
PANELLING ,R 256788, Replaced By: A9016307707, +001A9016300067
5
PANELLING PEDESTAL WITH DOORS
8
PANELLING PEDESTAL WITH DOORS, TO BE ADAPTED DURING ASSEMBLY ONLY FOR SECTIONAL REPAIR WORK
10
PLATE WITH THREADED HOLES
11
WHEEL BOW LEFT
11
13
REINFORCEMENT LEFT
14
RECESS WITH CUTOUT FOR TANK FILLER,R 256788
17
FLAP TANK FLAP
20
SPRING
23
RUBBER BUFFER
26
HEXALOBULAR BOLT WINDOW REGULATOR AT BRACKET AND DOOR M6X16
26
SCREW , Replaced By: N000000002202
30
OPERATING PLATE
