Mercedes N913023005002 - Гайка М5

314, 308 CDI, 311 CDI, 313 CDI, 316 CDI 903.663 TO IDENT-NR. R337626

54 ELECTRICAL EQUIPMENT AND INSTRUMENTS - 055 BATTERY,BATTERY CABLE,CUT-OFF RELAY AND CONTACTOR

Поз.
Артикул
Описание
5
A9017111234
CONNECTION
10
A9017112801
PARTITION PANEL
15
A9017100120
RAIL
20
A0019906397
RIVET
25
A9017100002
INTERIOR DOOR , TO BE ADAPTED DURING ASSEMBLY
30
N000000002210
BLIND RIVET PARTITION PANEL TO CONNECTION SUPPORT 5X25
30
N000000002223
BLIND RIVET PARTITION WALL ON B-PILLAR 5X25
40
A9017180009
DOOR PULL HANDLE
45
A9017180109
DOOR PULL HANDLE
50
N000000001474
HEXALOBULAR BOLT CAN NEUTRAL POINT ON EQUIPMENT PLATE M6X10, Replaced By: A0019844329
55
A9017600688
ADJUSTER. CATCH
60
N304017004006
HEXAGON HEAD BOLT AIR GRILLE FASTENING M4X16
65
N304032004002
NUT BOOT TO AIR DUCT AND TO AIR CLEANER
70
A9017100035
CATCH
72
A6707600105
TUMBLER WITH LOCK DEFINED, STATE LOCK NUMBER WHEN ORDERING
73
A6707600205
TUMBLER WITH KEY, ANY LOCK,K 057755
75
N007337005002
RIVET
80
A9017660079
HOOK
85
N000000001476
HEXALOBULAR BOLT BASIC MODULE AT SUPPORT M6X16,01.08.08
90
A9017110475
EDGE GUARD SECTION
95
A9017100828
GUIDE RAIL
100
N000000002292
SCREW5X45
100
N000000002208
SCREWM5X16
105
N913023005002
NUT RELAY TO BRACKET M5
108
N007337005002
RIVET
110
A9016020418
RAIL
115
A9017112701
PARTITION PANEL LEFT
120
A9017110038
BINDING RAIL , NO LONGER AVAILABLE
125
A0019906597
RIVET PARTITION PANEL TO BODY 4.8X10 MM
130
A9017660213
BUFFER
135
A9017100106
STOP DOOR
140
N000603008026
SCREW STOP TO BEARING BRACKET
145
N913023008003
NUT HORN TO BRACKET M8
150
A9017120098
SEAL
160
A9015840047
WARNING STRIP
