Поз.
Артикул
Описание
12
BALL PIVOT CONTROL LEVER TO INJECTION PUMP LEVER, Replaced By: N000000004467
12
SCREW CONTROL LEVER TO INJECTION PUMP LEVER
12
BALL PIVOT LOAD SENSOR
15
NUT , Replaced By: N913004006001
15
NUT PUMP TO BRACKET
39
BALL SOCKET ROD TO ACCELERATOR PEDAL
42
CIRCLIP. SECURING CLIP BALL SOCKET TO ROD
45
BEARING TUBE ,5 151593, Replaced By: A6153000021, +001A6153000020
45
BEARING TUBE CONTROL SHAFT,5 151594
48
BUSHING INTERMEDIATE LEVER TO BEARING BRACKET,5 943507
51
SHAFT ,5 151593, Replaced By: A6153000020, +001A6153000021
51
SHAFT CONTROL,5 151594
54
BALL PIVOT
57
LEVER (CONTROL LEVER)
60
BALL PIVOT
63
CLAMPING SLEEVE , Replaced By: N308752004001
63
CLAMPING PIN CONTROL LEVER TO CONTROL SHAFT, TO BE ADAPTED DURING ASSEMBLY
66
SCREW , Replaced By: N304017008016
66
SCREW OIL-DIPSTICK GUIDE TUBE TO BRACKET
69
NUT , Replaced By: N913004008001
69
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
69
HEXAGON NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET
75
ROD , Replaced By: A3604301992
75
ROD FROM ACCELERATOR PEDAL TO INTERMEDIATE LEVER
78
BALL SOCKET PULL ROD TO LEVER
81
NUT BALL PIVOT TO LEVER
84
CIRCLIP. SECURING CLIP BALL SOCKET TO ROD
90
BEARING BRACKET ,5 324163, Replaced By: A6203000836, +002A6153010088
90
BEARING BRACKET , Replaced By: A6583000036, +001A6583000228
90
BEARING BRACKET INTERMEDIATE BEARING,5 324164
97
LEVER INTERMEDIATE BEARING
99
BALL PIVOT , Replaced By: A3129910120
99
BALL PIVOT LEVER
102
BALL PIVOT BOTTOM B13X5 MM
105
BUSHING INTERMEDIATE LEVER TO BEARING BRACKET,5 943507
105
BUSHING INTERMEDIATE LEVER TO BEARING BRACKET,5 943507
108
COVERING , Replaced By: A6153010088
108
COVERING INTERMEDIATE BEARING
111
LOCK PLATE INTERMEDIATE BEARING
114
SCREW , Replaced By: N304017008034
114
SCREW BRACKET TO CROSS CONNECTION STRUT
116
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
123
PULL ROD FROM CONTROL SHAFT BEARING TO ENGINE SHAFT, TO BE ADAPTED DURING ASSEMBLY
126
BALL SOCKET ROD TO BALL PIVOT
129
BALL SOCKET ROD TO BALL PIVOT
131
NUT , Replaced By: N304032008006
131
NUT
134
SECURING CLIP. CIRCLIP
165
BRACKET WIRE CABLE TO FRAME SIDE MEMBER, 415 5 014669 416 5 000516 417 4 972024
171
CLAMPING PIECE CABLE TO BRACKET
999
SCREW GUIDE RAIL RETROFIT M 6X35, BORE THREADED HOLES IN CAB FLOOR TO 6.5MM
999
SCREW COVER PLATE TO BRACKET
999
SCREW CONNECTOR
999
WASHER COMPRESSED AIR LINE TO BRACKET
999
WASHER COMPRESSED AIR LINE TO BRACKET, Replaced By: N000125006449
999
GUIDE RAIL ACCELERATOR PEDAL TO FLOOR PLATE
999
CLAMPING PIECE CABLE PULL TO FIRE WALL
999
PAD ACCELERATOR PEDAL
999
CLAMPING PIECE FLEXIBLE SHAFT TO FRAME SIDE MEMBER
999
GUIDE MANUAL CONTROL
