Поз.
Артикул
Описание
23
RADIATOR
25
TANK EXPANSION TANK, UP TO IDENT NO. 004702 EXCEPT FOR 004316,004586,004634,004640,004650,004662,004673
31
HOSE FEED & RETURN LINES TO HEAT EXCHANGER EXCHANGER, TO BE ADAPTED DURING ASSEMBLY
33
CLAMP SUCTION LINE TO OIL PUMP 40-60X13 MM
33
CLAMP , Replaced By: N000000000671
40
HOSE FEED AND RETURN LINE CONNECTION, LENGTH AVAILABLE 1000 MM
50
GASKET OUTLET TO ENGINE
52
LINE FROM ENGINE TO OIL COOLER,FIRST PART
54
LOCK WASHER BRACKET TO SUPPORT AND TO END PIECE
58
SCREW CLUTCH TO FLYWHEEL
58
SCREW BRACKET TO SIDE MEMBER
58
SCREW , Replaced By: N304017010002
58
SCREW SUPPORT TO CROSS MEMBER M 10X28
62
SEAL RING CONNECTION: 1,4 719029
64
SCREW PLUG RELAY VALVE,CONNECTION "20",RIGHT
66
HOSE FROM RADIATOR TO WATER PUMP,833480-4 197805
66
HOSE LINE CONNECTION 28X37X80 MM
68
HOSE FROM ENGINE TO CONNECTION HOSE, FEED
74
CLAMP HOSE FASTENING 50-70X13 MM
74
CLAMP SUCTION LINE TO OIL PUMP 40-60X13 MM
74
CLAMP , Replaced By: N000000000671
79
CLAMP HOSE FASTENING 50-70X13 MM
79
CLAMP
79
CLAMP , Replaced By: N000000000670
82
OUTLET FROM ENGINE TO CONNECTION HOSE, FEED,003426
82
OUTLET FROM ENGINE TO CONNECTION HOSE, FEED,003426
82
OUTLET FEED LINE TO ENGINE
84
THREADED INSERT FROM ENGINE TO CONNECTION HOSE, FEED,003426
88
LINE FROM ENGINE TO OIL COOLER,SECOND PART,003426
94
BRACKET COOLING WATER LINE
106
LINE
108
LINE FROM HOSE TO RADIATOR,000702
129
COOLING WATER PIPE FROM HOSE TO RADIATOR,001359
129
COOLING WATER PIPE FROM HOSE TO RADIATOR,000702
133
HOSE COOLING WATER LINE
136
HOSE
139
CLAMP HOSE FASTENING 50-70X13 MM
139
CLAMP , Replaced By: N000000000672
145
COOLING WATER PIPE FROM HOSE TO MOLDED HOSE,003004
149
COOLING WATER PIPE FROM HOSE TO MOLDED HOSE,003005
158
HOSE COOLING WATER LINE
163
COOLING WATER PIPE WATER PUMP,000702
169
HOSE FROM ENGINE TO CONNECTION HOSE, FEED
179
CLAMP SUCTION LINE TO OIL PUMP 40-60X13 MM
179
CLAMP , Replaced By: N000000000671
180
HOSE COOLING WATER LINE,021573
182
INTAKE PIPE SOCKET RETURN LINE TO ENGINE
182
INTAKE PIPE SOCKET , Replaced By: A4032011930
184
GASKET
184
GASKET FLANGE TO PUMP
188
LOCK WASHER PARKING BRAKE VALVE TO WINDOW SILL
188
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
194
HEXALOBULAR BOLT. SCREWM 8X45
194
SCREW STEERING SHAFT BEARING TO CAB M 8X30,5 191030
194
SCREW CLAMP TO CONNECTING PIPE AND TO EXHAUST HOSE M 8X30
194
SCREW , Replaced By: N304017008027
218
CLAMP SAFETY VALVE AT BRACKET
220
SCREW PIPE CLAMP
222
NUT , Replaced By: N913004008001
229
HOSE
236
CONNECTING PIPE DE-AERATION LINE,002596
245
HOSE PRESSURE REGULATOR,ANTI-FREEZE DEVICE, ORDER BY THE METER
247
CLAMP HOSE TO FITTING AND TO OIL TANK 16-27X13 MM
247
CLAMP HOSE TO FITTING AND TO OIL TANK
254
CLAMP DELIVERY AND SUCTION LINES TO ENGINE, FRONT
254
CLAMP LINES TO BRACKET
254
CLAMP DELIVERY AND SUCTION LINES TO ENGINE, FRONT
254
CLAMP LINE MOUNTING
258
SCREW LONGITUDINAL DIFFERENTIAL LOCK VALVE TO BRACKET,5 963747
258
SCREW CAB FLOOR COVERING M 6X25
264
NUT
999
MASTER CYLINDER CLUTCH "KUGELFISCHER"
999
LINE FROM VALVE TO CONNECTION FITTING,K 172343 ORDER BY THE METER
999
RESERVOIR LESS WARNING DEVICE ATE
999
T-FITTING
999
PIN CONNECTOR TO PEDAL ASSEMBLY BEARING BRACKET,001828
999
CLAMP , Replaced By: N916016012201
999
CLAMP , Replaced By: N916016020201
999
CLAMP , Replaced By: N916016008201
999
CLAMP , Replaced By: N916016015202
999
CLAMP , Replaced By: N916016022202
999
CLAMP , Replaced By: N916016038201
999
LOOM TIE , Replaced By: N916017011000
999
LOOM TIE , Replaced By: N916017020000
999
LOOM TIE
999
LOOM TIE , Replaced By: N916017040000
999
LOOM TIE , Replaced By: N916017040000
999
LOOM TIE , Replaced By: N916017050000
999
RUBBER BUFFER EXHAUST MUFFLER
999
NEEDLE BEARING , Replaced By: A0059813110
999
HOSE , Replaced By: A0009978952
999
HOSE , Replaced By: A0109975982
999
SEAL RING
999
GROMMET CABLE THROUGH ELECTRICAL COMPARTMENT,002062 ON VEHICLES HAVING NO MERCEDES-BENZ BODY UP TO IDENT NO. 017956 EXCEPT FOR 017867,017919
999
SCREW CLUTCH PEDAL RELEASE SPRING
999
COVER PLATE
999
PAD BRAKE PEDAL
999
RADIATOR , Replaced By: A3055010501
999
PEDAL CLUTCH
999
BEARING BRACKET PEDAL ASSEMBLY
999
PEDAL PLATE CLUTCH
999
BRACKET
999
CONNECTOR , UP TO IDENT NO.002623 EXCEPT FOR 002595,002607,002610,002611, Replaced By: A3072901843, +001A3072900533
999
BUSHING , UP TO CHASSIS 000161 EXCEPT FOR 000041,000047,000048 000105,000120
999
PIPE , Replaced By: A0004290801
999
ROD FROM CLUTCH PEDAL TO MASTER CYLINDER
999
ROD , Replaced By: A3053001415, +002N071805010204, +002N071805010403, +001N900331006615
999
999
CONNECTING PIPE , Replaced By: A3075060759
999
SEAL
999
WASHER CLUTCH PEDAL TO BEARING BRACKET
999
SPRING CLUTCH PEDAL
999
YOKE FROM CLUTCH PEDAL TO MASTER CYLINDER
999
FITTING CLUTCH SLAVE CYLINDER
999
SCREW , Replaced By: N000000001448
999
SCREW , Replaced By: N304017008021
999
GASKET , Replaced By: N917003040006
999
GASKET. SEAL , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A3559970149
