Поз.
Артикул
Описание
5
COOLING WATER PIPE
8
COOLING WATER PIPE FEED D60MM
11
11
14
COOLING WATER PIPE
32
BREATHER PIPE
35
BRACKET ALTERNATOR
44
HOSE ,D 209702
47
HOSE
50
MOLDED HOSE ARC REDUCED 90 DEGREES 70/60MM
53
MOLDED HOSE 90-DEGREE ARC D60
56
MOLDED HOSE NARROWED STRAIGHT SURFACE 65/60
59
MOLDED HOSE ARC REDUCED 45 DEGREES 70/60MM
68
HOSE10X19X100MM
68
HOSE10X19X160MM
68
HOSE670LG
68
HOSE10X19X240MM, TO BE ADAPTED DURING ASSEMBLY
71
MOLDED HOSE ARC REDUCED 90 DEGREES 15/10MM
74
HOSE WITH CHECK VALVE
77
77
HOSE12X21X350MM
89
CLAMP HOSE TO RADIATOR AND TO EXPANSION TANK 12-22X13 MM
92
CLAMP HOSE TO INTAKE PIPE 35-50X13MM
95
CLAMP CONNECTION OF COOLING WATER LINES 55-75X13MM
98
CLAMP HOSE TO RADIATOR,PIPE ELBOW,AND WATER PUMP 60-80X13 MM
101
CLAMP
104
SCREW. HEXAGON HEAD BOLT BUZZER TO WINDOW LEVEL GIRDER M6X25
104
SCREW BRACKET AND CLAMP M6X20
110
SCREW , Replaced By: N910143008002
113
HEXAGON HEAD BOLT. SCREW BRACKET TO SIDE MEMBER M8X35
119
HEXAGON HEAD BOLT RESONATOR TO TRANSMISSION CASE,K 138633
119
SCREWM 10X20
122
SCREW BRACKET TO SUPPORT M 12X25,K 574789
122
HEXAGON HEAD BOLT BRACKET TO SIDE MEMBER M12X1.5X35
131
NUT BRACKET TO FIRE WALL
134
NUT HORN TO BRACKET M8
137
NUT EXHAUST PIPE AND PIPE CLAMP TO BRACKET
140
NUT BRACKET TO SIDE MEMBER M12X1.5
143
CLAMP LINE MOUNTING 10/15, Replaced By: N000000007511
143
CLAMP10/15
143
CLAMP , Replaced By: N916016010211
146
CLAMP60/25MM, Replaced By: N000000006126
146
CLAMP BRAKE HOSE BRACKET
146
CLAMP PIPE ON FAN SHROUD
146
CLAMP CLAMP ON TRANSVERSE SHAFT MOUNTING, LINKAGE
146
CLAMP60/25RSGU
146
CLAMP60/25
146
CLAMP LINE MOUNTING 15-18 MM,V 207570
149
BANJO UNION10/14
149
BANJO UNION12/18MM
149
BANJO UNION SUCTION LINE
152
HOLLOW SCREWA15
152
HOLLOW SCREW , Replaced By: N915036015201
152
SCREW
152
HOLLOW SCREW
152
HOLLOW SCREW HAND BRAKE VALVE,CONNECTION: "20"
155
SEAL RING VALVE TO VALVE,K 025179
158
SCREW PLUG FUEL TANK
158
SCREW PLUG, FILLINGM14X1,5
161
SEALING RING. SEAL RING ENGINE BREATHING
164
BRACKET
173
GROMMET
445
CLAMP LINE MOUNTING 15-18 MM,V 207570
445
MOUNTING CLAMP SUCTION/DELIVERY/RETURN LINES 18/15 MM
450
MOUNTING CLAMP MOUNTING USED FOR COMPRESSED AIR LINES RSGU 20/15
450
CLAMP CLAMP ON TRANSVERSE SHAFT MOUNTING, LINKAGE
