Поз.
Артикул
Описание
130
BRACKET
140
HEXAGON HEAD BOLT BRACKET TO BRACKET
140
SCREW , Replaced By: N308676012012
140
SCREW. HEXAGON HEAD BOLT VALVE TO BRACKET
140
SCREW , Replaced By: N308676012013
140
HEXAGON HEAD BOLT , Replaced By: A0029902704
140
SCREW EXHAUST PIPE TO BRACKET
140
SCREW , Replaced By: A9429901304
140
SCREW APPARATUS SUPPORT TO FRAME
150
WASHER , Replaced By: N007349013005
150
WASHER MOUNTING USED FOR FRAME CONNECTION PARTS
150
WASHER STRUT TO CROSS MEMBER
160
NUT CROSS MEMBER TO SIDE MEMBERS
160
NUT , Replaced By: N910113012003
160
HEXAGON NUT EXHAUST PIPE TO BRACKET ON SIDE MEMBER
160
NUT STEERING SUPPORT TO FRAME
170
BRACKET BRACKET TO FRAME
180
SCREW , Replaced By: N304017010040
180
SCREW STRUT TO CROSS MEMBER M 10X25
190
SCREW , Replaced By: N308676014003
190
HEXAGON HEAD BOLT. SCREW ENGINE MOUNTING TO SUPPORT,ON CLUTCH END M 14X30
190
SCREW , Replaced By: N308676014008
190
SCREW MOUNTING TO CONSOLE M 14X35
200
NUT CROSS MEMBER TO SIDE MEMBERS
210
NUT STEERING SUPPORT TO FRAME
230
SUPPORT EXHAUST MUFFLER
240
SCREW END PIECE TO EXHAUST PIPE M 10X25
250
WASHER , Replaced By: N009021010209
250
WASHER BRACKET TO COVERING
250
WASHER , Replaced By: N000125010532
250
WASHER RADIATOR TO RUBBER MOUNTING
260
NUT , Replaced By: N910113010000
260
NUT STRAP TO BRACKET
270
BRACKET
290
SCREW , Replaced By: N304017010002
290
SCREW BRACKET TO SIDE MEMBER
290
SCREW BRACKET TO CAB CONSOLE,K 035197
310
WASHER , Replaced By: N009021010209
310
WASHER BRACKET TO COVERING
310
WASHER , Replaced By: N000125010532
310
WASHER RADIATOR TO RUBBER MOUNTING
320
NUT , Replaced By: N910113010000
320
NUT STRAP TO BRACKET
320
NUT , Replaced By: N308673014001
320
NUT BRACKET TO SIDE MEMBER,K 035196
340
BRACKET EXHAUST MUFFLER TO FRAME
340
BRACKET EXHAUST MUFFLER TO FRAME
350
SCREW , Replaced By: N304017010002
350
SCREW BRACKET TO SIDE MEMBER
350
SCREW BRACKET TO FRAME M 12X35
350
SCREW BRACKET TO CAB CONSOLE,K 035197
350
SCREW , Replaced By: N308676014020
350
SCREW BRACKET TO SIDE MEMBER M 14X1.5X35
360
WASHER , Replaced By: N009021010209
360
WASHER BRACKET TO COVERING
360
WASHER , Replaced By: N000125010532
360
WASHER RADIATOR TO RUBBER MOUNTING
370
NUT , Replaced By: N910113010000
370
NUT STRAP TO BRACKET
370
NUT STRAP TO SUPPORT
370
NUT , Replaced By: N308673014001
370
NUT BRACKET TO SIDE MEMBER,K 035196
370
NUT BRACKET TO SIDE MEMBER,K 035196
880
PROTECTIVE PLATE REAR EXHAUST PIPE, NOT USED
910
SCREW CLAMP TO BRACKET AND TO PIPE
930
WASHER , Replaced By: N000125008443
930
WASHER EXHAUST MUFFLER TO STRAP
960
BRACKET FENDER
970
SUPPORT (CONSOLE),FOR FENDER
980
BRACKET LEFT FENDER
980
BRACKET LEFT FENDER
999
NUT REINFORCEMENT TO BRACKET
999
NUT EXHAUST PIPE AND PIPE CLAMP TO BRACKET
999
SCREW CLAMP TO BRACKET,5 597426
999
NUT SUPPORT TO SIDE MEMBER
999
NUT , Replaced By: N913023010002
999
HEXAGON HEAD BOLT. SCREW BRACKET TO FRAME M 10X30
999
CLAMP SLIDING PIECE TO EXHAUST PIPE
999
SCREW CONSOLE TO SIDE MEMBER
999
STUD BOLT BELL HOUSING, 760272 10/20 UP TO IDENT NO. 922885 EXCEPT FOR 921682,921950,921972,921994,922001,922008,922038,922287,922349,922387,922522,922575,922585,922608, 922638,922642,922671,922678,922686,922691,922705,922720,922723,922732,922736,922756,922768,922850, 922855. ALSO INSTALLED ON 934036,934433,934539,935068,935169,937098 50/60 UP TO IDENT NO. 922468 ON 96 KW (130 PS) 50/60 UP TO IDENT NO. 923153 ON 124 KW (168 PS)
999
NUT BRACKET TO SIDE MEMBER
999
SCREW REAR EXHAUST PIPE TO MUFFLER
999
SCREW EXHAUST PIPE TO BRACKET
999
WASHER
999
END PIECE
999
EXHAUST PIPE FRONT
999
EXHAUST PIPE FRONT
999
EXHAUST MUFFLER
999
BRACKET
999
CLAMP
999
EXHAUST PIPE FRONT
999
BRACKET LEFT FENDER
999
BRACKET LEFT
999
SCREW BRACKET TO FRAME
999
SCREW , Replaced By: N910142008009
999
NUT CONSOLE TO SIDE MEMBER
999
NUT BRACKET TO BRACKET
