Поз.
Артикул
Описание
5
BRAKE PRESSURE REGULATOR ALB REGULATOR TO RELAY VALVE WABCO
8
REPAIR KIT BRAKE POWER REGULATOR WABCO
11
HEXAGON NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET
11
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
11
NUT , Replaced By: N913004008001
18
BRACKET RELAY VALVE
20
SCREW BRACKET TO SIDE MEMBER
20
SCREW , Replaced By: N304017010002
29
NUT STRAP TO BRACKET
29
NUT , Replaced By: N910113010000
35
GUIDE SIGN LOAD-DEPENDING BRAKE,5 557360
36
ADHESIVE FOIL GUIDE SIGN
41
SCREW. UNION SCREW LINE CONNECTION
44
SCREW. UNION SCREW LINE CONNECTION
44
SCREW. UNION SCREW , Replaced By: A0009973734
47
LEVER BRAKE POWER REGULATOR CONTROL, TO BE ADAPTED DURING ASSEMBLY
50
PULL ROD BRAKE POWER REGULATOR CONTROL 200 MM, TO BE ADAPTED DURING ASSEMBLY
56
BALL SOCKET PULL ROD
56
BALL SOCKET PULL ROD, Replaced By: A0009918222
59
CONNECTOR PULL ROD TO LEVER
65
CLAMP HOSE TO RADIATOR AND TO EXPANSION TANK 12-22X13 MM
65
CLAMP , Replaced By: N000000000665
68
CLAMP CONNECTOR TO BRAKE PRESSURE REGULATOR LEVER
74
WASHER EXHAUST MUFFLER TO STRAP
74
WASHER , Replaced By: N000125008443
80
COTTER PIN CONNECTOR TO BRAKE PRESSURE REGULATOR LEVER
83
NUT
89
METAL SPRING BELLOWS ,4 9579425 498312
92
SCREW OIL-DIPSTICK GUIDE TUBE TO BRACKET
92
SCREW , Replaced By: N304017008016
95
SCREW. HEXAGON HEAD BOLT VALVE TO BRACKET
95
SCREW , Replaced By: N308676012012
96
WASHER EXHAUST MUFFLER TO STRAP
96
WASHER , Replaced By: N000125008443
98
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
101
LOCK WASHER FITTING TO BRACKET
104
BRACKET METAL SPRING BELLOWS
110
CONSOLE METAL SPRING BELLOWS
122
COVERING INTERMEDIATE BEARING
122
COVERING
125
BUSHING INTERMEDIATE LEVER TO BEARING BRACKET,5 943507
128
WASHER BEARING BRACKET TO BRACKET
131
COTTER PIN CYLINDER TO BRACKET
