Поз.
Артикул
Описание
5
HOSE FROM RADIATOR TO THERMOSTAT
5
HOSE FROM RADIATOR TO THERMOSTAT, TO BE ADAPTED DURING ASSEMBLY
8
CLAMP HOSE TO RADIATOR,PIPE ELBOW,AND WATER PUMP 82 - 105 X 15.8 MM
8
CLAMP , Replaced By: A0059972990
8
CLAMP HOSE 70-90X13 MM
8
CLAMP , Replaced By: N000000000674
11
HOSE FROM RADIATOR TO WATER PUMP
11
HOSE FROM RADIATOR OUTLET TO WATER PUMP
14
PIPE ELBOW AT WATER PUMP,5 510518
14
PIPE ELBOW AT WATER PUMP,5 1935955 510517
14
PIPE ELBOW , Replaced By: A6555010756
15
PIPE ELBOW FOR SCREW FITTING
17
SCREW BRACKET TO FRAME SIDE MEMBER
18
PIN PIPE ELBOW TO BRACKET,K 023462
19
SPACER RING PIPE ELBOW TO BRACKET,K 023462
20
NUT STRAP TO BRACKET
20
NUT , Replaced By: N910113010000
23
HOSE FROM RADIATOR OUTLET TO WATER PUMP, ORDER BY THE METER
26
CLAMP HOSE TO RADIATOR,PIPE ELBOW,AND WATER PUMP 82 - 105 X 15.8 MM
26
CLAMP , Replaced By: A0059972990
26
CLAMP HOSE 70-90X13 MM
26
CLAMP , Replaced By: N000000000674
30
CONNECTOR FOR SCREW FITTING
32
GASKET CONNECTOR
32
GASKET CONNECTOR, Replaced By: A0002011280
32
GASKET CONNECTOR, Replaced By: A0002011180
32
GASKET CONNECTOR, Replaced By: A0002011080
35
SCREW STRAP TO BRACKET
35
SCREW END PIECE TO EXHAUST PIPE M 10X25
45
HOSE FROM WATER PUMP TO EXPANSION TANK AND TO HEATING PIPE
45
HOSE FROM WATER PUMP TO EXPANSION TANK AND TO HEATING PIPE,K 003668
62
CLAMP HOSE TO SUCTION LINE AND TO OIL TANK 20-32X13 MM
62
CLAMP
65
BREATHER PIPE FROM ENGINE TO EXPANSION TANK,5 528984
65
BREATHER PIPE ENGINE BREATHING
68
GASKET. SEAL DE-AERATION PIPE TO ENGINE
71
SCREW END PIECE TO EXHAUST PIPE M 10X25
74
HOSE FROM RESERVOIR TO CONNECTION FITTING
77
CLAMP HOSE TO FITTING AND TO OIL TANK 16-27X13 MM
77
CLAMP HOSE TO FITTING AND TO OIL TANK
999
WASHER , Replaced By: A1894660751
999
BREATHER PIPE FROM ENGINE TO EXPANSION TANK
999
HOSE , Replaced By: A6565010782
