Поз.
Артикул
Описание
10
CLUTCH PRESSURE PLATE , PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
20
PRESSURE PLATE
30
RELEASE LEVER CLUTCH ACTUATION
40
SPINDLE FOR BEDDING THE LEVERS IN CLUTCH PRESSURE PLATE
50
BRACKET RELEASE LEVER
60
LOCK PLATE RELEASE LEVER TO SHAFT
70
LEAF SPRING THIGH SPRING SUSPENDED BELOW LEAF SPRING
70
LEAF SPRING THIGH SPRING SUSPENDED IN CLUTCH PRESSURE PLATE HOUSING
80
SPINDLE FOR BEDDING THE LEVERS IN BRACKETS
90
ROLLER FOR BEDDING THE LEVERS IN BRACKETS
100
COTTER PIN
110
PRESSURE SPRING SPRING STEEL WIRE DIA., 4.00 MM
110
PRESSURE SPRING SPRING STEEL WIRE DIA., 3.75 MM
120
SPRING SUSPENDED BELOW LEAF SPRING
120
SPRING SUSPENDED IN CLUTCH PRESSURE PLATE HOUSING
120
SPRING SUSPENDED IN CLUTCH PRESSURE PLATE HOUSING
130
SPRING SUSPENDED BELOW LEAF SPRING
140
CLAMP RELEASE FLANGE TO RELEASE LEVER
150
FLANGE
160
NUT FOR BRACKETS
170
LOCK FOR BRACKETS
180
LOCK WASHER BRACKET TO STEERING COLUMN END
190
SCREW BATTERY CABLE MOUNTING AND MAIN CABLE HARNESS MOUNTING
200
CLUTCH PRESSURE PLATE (TWIN PLATE CLUTCH) CLUTCH DISC LINING ASBESTOS-FREE, PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
200
CLUTCH PRESSURE PLATEVALEO, COMPONENT PARTS NOT AVAILABLE PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
200
CLUTCH PRESSURE PLATE , COMPONENT PARTS NOT AVAILABLE PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
200
CLUTCH PRESSURE PLATE , PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
200
CLUTCH PRESSURE PLATE , MUST NOT BE DISASSEMBLED
200
CLUTCH PRESSURE PLATEFICHTEL&SACHS,K 017132 PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
200
CLUTCH PRESSURE PLATE
200
CLUTCH PRESSURE PLATE , PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
200
CLUTCH PRESSURE PLATE , PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
200
CLUTCH PRESSURE PLATE , TO BE ADAPTED DURING ASSEMBLY, Replaced By: A0052508804
200
CLUTCH PRESSURE PLATE (TWIN PLATE CLUTCH) CLUTCH DISC LINING ASBESTOS-FREE,K 017132
210
RELEASE RING REPAIR KIT TO 005 250 83 04
210
CLUTCH PRESSURE PLATE REPAIR KIT TO 005 250 87 04, 88 04
230
CLUTCH DISC , MUST NOT BE DISASSEMBLED
230
CLUTCH DISC ON TRANSMISSION END,ASBESTOS-FREE LINING
230
CLUTCH DISC ASBESTOS-FREE LINING
230
CLUTCH DISC
230
CLUTCH DISC ASBESTOS-FREE LINING, PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
230
CLUTCH DISC , PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
230
CLUTCH DISC , PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
230
CLUTCH DISC
230
CLUTCH DISC ON TRANSMISSION END,ASBESTOS-FREE LINING, PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
230
CLUTCH DISC ASBESTOS-FREE LINING
230
CLUTCH DISC ASBESTOS-FREE LINING, PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART COMPONENT PARTS NOT AVAILABLE
230
CLUTCH DISC , Replaced By: A0172504803
230
CLUTCH DISC , Replaced By: A0172504803
230
CLUTCH DISC , Replaced By: A0162503803
230
CLUTCH DISC , Replaced By: A0142507703
230
CLUTCH DISC , Replaced By: A0162504003
230
CLUTCH DISC , Replaced By: A0142507703
230
CLUTCH DISC , Replaced By: A0172504803
230
CLUTCH DISC , Replaced By: A0132507903
230
CLUTCH DISC , Replaced By: A0132507903
230
CLUTCH DISC ASBESTOS-FREE LINING, PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
230
CLUTCH DISC ON ENGINE END, ASBESTOS-FREE LINING, PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
250
CLUTCH LINING ASBESTOS-FREE,5 563495
250
CLUTCH LINING ASBESTOS-FREE
250
CLUTCH LINING ASBESTOS-FREE
260
LEAF SPRING
260
LEAF SPRING ,5 563495
280
RIVET LINING WITH CLUTCH DISC,5 563495
280
RIVET LEAF SPRING TO CLUTCH DISC
290
RIVET LINING WITH CLUTCH DISC
290
RIVET LINING WITH INTERMEDIATE SPRING,5 563495
300
SCREW CLUTCH TO FLYWHEEL
300
SCREW CLUTCH PRESSURE PLATE TO FLYWHEEL
300
SCREW CLUTCH TO FLYWHEEL
310
LOCK WASHER BRACKET TO SUPPORT AND TO END PIECE
