Поз.
Артикул
Описание
8
LINE , Replaced By: A1234208128
8
LINE FROM MASTER CYLINDER TO CONNECTOR
8
LINE FROM PRESSURE RETAINING VALVE TO RIGHT REAR BRAKE HOSE 3090 MM,P 136599
11
CLAMP
11
CLAMP ELECTRIC CABLE TO BRAKE HOSE
11
CLAMP. EXTENDABLE SPACER BREATHER LINE
11
BRACKET OIL LINES
14
BRACKET OIL LINES
14
CLAMP. EXTENDABLE SPACER BREATHER LINE
14
CLAMP , Replaced By: A0009956665
14
CLAMP
17
CLAMP. EXTENDABLE SPACER BREATHER LINE
17
BRACKET OIL LINES
20
BRACKET BRAKE LINES
23
CLAMP , FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO.F 076976, Replaced By: A1244760940
26
BRACKET RELEASE SPRING,625235
29
ADAPTER FITTING BETWEEN THE LINES
32
LINE FROM HEIGHT CONTROL VALVE TO LEFT SPRING-LOAD ACCUMULATOR
32
LINE FROM MASTER CYLINDER TO REAR BRAKE PRESSURE REGULATOR
32
LINE FROM DISTRIBUTOR TO REAR HEIGHT CONTROL VALVE
35
BRAKE HOSE FRONT AND REAR AXLES
35
BRAKE HOSE BRAKE LINE TOWARDS DISTRIBUTOR
35
BRAKE HOSE FRONT
38
BRACKET LINE TO SIDE MEMBER, 957591 N 000000 P 000000
41
CLAMP
44
BRACKET OIL LINES
44
CLAMP. EXTENDABLE SPACER BREATHER LINE
44
CLAMP ELECTRIC CABLE TO BRAKE HOSE
47
DOUBLE CLAMP. CLAMP CABLE HARNESS MOUNTING,P 217441
50
RETAINING SPRING BRAKE HOSE TO BRACKET
53
BRACKET LINE TO SHOCK ABSORBER, 957592 N 000001 P 000001
56
LINE FROM DISTRIBUTOR TO CYLINDER, N 000000 P 062026
59
BRACKET BRAKE HOSE TO FRAME
59
BRACKET , Replaced By: A6704230323
64
DISTRIBUTOR REAR AXLE, N 000000 P 062026
72
BRACKET DISTRIBUTOR TO REAR AXLE
80
WASHER FROM SLAVE CYLINDER TO HOSE,895778
88
NUT HEATING PIPE TO BRACKET
96
BRACKET TO BRACKET,STEERING GEAR 28.06, NOT CARRIED AS A SPARE PART
96
BRACKET , Replaced By: A4064261540
99
CLAMP FROM DISTRIBUTOR TO CYLINDER
102
SCREW MOUNTING PARTS M 5X12, Replaced By: N000000002035
104
LINE FROM HYDRAULIC UNIT TO LEFT FRONT WHEEL, ONLY APPLICABLE TO ANTI-LOCK BRAKING SYSTEM (ABS)F039532 TO BE ADAPTED DURING ASSEMBLY
107
LINE FROM ADAPTER FITTING TO DISTRIBUTOR,126.021 005796, 126.022,023 020032, 126.032,033 008371, 126.036,037 007212
107
LINE FROM MASTER CYLINDER TO FRONT BRAKE PRESSURE REGULATOR
107
LINE FROM BRAKE POWER REGULATOR TO RIGHT FRONT WHEEL 2000 MM
107
LINE FROM ADAPTER FITTING TO DISTRIBUTOR,126.021 005796, 126.022,023 020032, 126.032,033 008371, 126.036,037 007212
107
LINE FROM VALVE TO LEFT REAR WHEEL 3560 MM
107
LINE FROM MASTER CYLINDER TO HOSE 2890 MM
107
LINE FROM PRESSURE RETAINING VALVE TO RIGHT REAR BRAKE HOSE 3090 MM,P 136599
110
BRACKET
113
BRACKET BRAKE LINE TO FIRE WALL
116
SHEET METAL SCREW COVERING TO CAB
119
SCREW BRACKET TO CONSOLE
120
NUT CROSS MEMBER TO SIDE MEMBERS
122
BRACKET
125
LOOM TIE LINE MOUNTING 280 MM
125
LOOM TIE LINE MOUNTING
