Поз.
Артикул
Описание
5
THROTTLE HOUSING PARTS KIT,K 181318N 817421 - N 825202
5
THROTTLE HOUSING PARTS KIT,K 181318N 817421 - N 825202
5
THROTTLE HOUSING , Replaced By: A3661405353
8
VALVE PARTS KIT,K 181319
8
VALVE PARTS KIT,K 181318N 817421 - N 825202
11
BUSHING
14
LEVER EXHAUST-BRAKE THROTTLE VALVE
14
LEVER , Replaced By: A3661400232, +001N913017006000, +001N914126006025
17
BALL PIVOT BOTTOM B13X5 MM
20
HEXALOBULAR BOLT. SCREW LINE MOUNTING M 6X30
20
SCREW , Replaced By: N000000001479
20
SCREW , Replaced By: N910105006005
20
SCREW LONGITUDINAL DIFFERENTIAL LOCK VALVE TO BRACKET,5 963747
23
NUT LEVER TO THROTTLE VALVE SHAFT TO 366 140 02 32
23
NUT , Replaced By: N913023006001
23
NUT , Replaced By: N910112006001
23
NUT BALL PIVOT TO LEVER
26
CYLINDER INTERMEDIATE SPEED STOP
26
CYLINDER , Replaced By: A0004304926
26
CYLINDER INCREASE IN NUMBER OF REVOLUTIONS KNORR
26
CYLINDER
26
CYLINDER , Replaced By: A0004303026
29
BUSHING"WABCO"
29
BUSHINGTO 000 430 30 26/32 26
29
BUSHING , Replaced By: A0004340850
32
REPAIR KITTO 000 430 48 26,KNORR
32
REPAIR KIT SHIFTING CYLINDER TO KNORR, SZ 1130 I/74963,000 430 3026
35
CAP SHIFTING CYLINDER TO 000 430 48 26 , 49 26
38
BALL SOCKET SHIFTING CYLINDER TO SHIFT LEVER
38
BALL SOCKET
41
SECURING CLIP. CIRCLIP
44
PIN INTERMEDIATE SPEED STOP
44
PIN CYLINDER TO BRACKET
44
PIN , Replaced By: A4421440574
47
WASHER INTERMEDIATE SPEED STOP
47
WASHER EXHAUST MUFFLER TO STRAP
47
WASHER , Replaced By: N000125008443
50
NUT , Replaced By: N913004008001
53
WASHER SUPPORTING RAIL TO SUPPORT,5 429712
59
NUT
62
BRACKET POWER CYLINDER, TO BE ADAPTED DURING ASSEMBLY
62
BRACKET , FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO. K 077169/N 817421 - 825202, Replaced By: A3661440440
65
SCREW BRACKET TO THROTTLE HOUSING M 8X16
68
SCREW STRUT TO FRAME M 12X62
68
SCREW , Replaced By: N308676012018
71
NUT THROTTLE HOUSING AND BRACKET TO FRONT EXHAUST PIPE
71
NUT , Replaced By: N910113012006
999
VALVE , Replaced By: A3661401963
999
THROTTLE HOUSING , Replaced By: A3661405353
