Поз.
Артикул
Описание
5
OIL FILLER NECK , Replaced By: A3640180304
5
PIPE ,5 293767
8
SCREW OIL FILLER NECK TO BRACKET,5 458408
8
SCREW OIL FILLER NECK TO BRACKET,5 458407
8
SCREW , Replaced By: N007985008182
11
BRACKET OIL FILLER PIPE TO RADIATOR,5 458408
11
BRACKET ,5 2937675 458407, Replaced By: A3640101540, +002A6739900301
11
BRACKET ,5 293766, Replaced By: A3640100640, +001A3520100468, +001A3640180304
14
SHIM OIL FILLER PIPE TO RADIATOR
17
SCREW BRACKET TO WATER RADIATOR
20
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
23
CAP OIL REFILLING,5 293767
23
CAP OIL REFILLING
23
CAP OIL REFILLING
23
CAP OIL REFILLING
26
GASKET , Replaced By: A1020180080
26
GASKET , Replaced By: A1020180380
26
GASKET
29
HOSE ,K 053730
32
CLAMP25-40X13 MM
32
CLAMP INTERMEDIATE PIPE TO PARTICLE FILTER
32
CLAMP
32
CLAMP , Replaced By: N000000000670
