Поз.
Артикул
Описание
5
REAR SPRING WITH HELPER SPRING
8
SPRING LEAFNO.1,TO 386 32076 08
11
BUSHING
11
BUSHING
14
SPRING LEAFNO.2,TO 386 320 76 08
17
SPRING LEAFNO.3,TO 386 320 76 08
20
SPRING LEAFNO.4,TO 386 320 76 08
23
SPRING LEAFNO.5,TO 386 320 76 08
29
SPRING LEAF HELPER SPRING NO.1,TO 386 320 76 08
32
SPRING LEAF HELPER SPRING NO.2,TO 386 320 76 08
35
SPRING LEAF HELPER SPRING NO.3,TO 386 320 76 08
38
SPRING LEAF HELPER SPRING NO.4,TO 386 320 76 08
41
SPRING LEAF HELPER SPRING NO.5,TO 386 320 76 08
44
SPRING LEAF HELPER SPRING NO.6,TO 386 320 76 08
47
SPACER
50
SPRING BOLTM 12X70
53
NUT BRACKET TO SIDE MEMBER
56
SHIM
59
SPACER
63
SHACKLE REAR-SPRING REAR BRACKET
65
BUSHING
65
BUSHING
68
SHACKLE PIN REAR SPRING TO SPRING SHACKLE AND TO SPRING FRONT AND REAR BRACKETS
71
GREASE NIPPLE PROTECTIVE TUBE
74
WASHER AS REQUIRED 4.2 MM
74
WASHER FRONT SPRING TO SPRING SHACKLE & SPRING BRACKETS
74
WASHER AS REQUIRED 4.0 MM
74
WASHER SHACKLE PIN, AS REQUIRED 4.0 MM
77
SEAL RING SPRING SHACKLE TO SPRING REAR BRACKET
80
BOLT SPRING SHACKLE TO SPRING REAR BRACKET
83
WASHER GROUND CABLE
86
NUT BRACKET TO SIDE MEMBER,XB209706
89
PLATE REAR SPRING TO REAR AXLE
89
PLATE , Replaced By: A6953257031
92
U-BOLT , Replaced By: A3583510125
95
SPACER FRONT SPRINGS TO FRONT AXLE
101
WASHER FRONT SPRINGS TO FRONT AXLE
104
NUT TORSION BAR TO BEARING BRACKET,5 904661
999
SPACER AT REAR AXLE
999
SPACER
999
SHIM4 MM
999
DOWEL PIN (CENTERING CONE)
