Поз.
Артикул
Описание
4
AXLE HOUSING. AXLE CASING STEEL VERSION
4
AXLE CASING STEEL VERSION
4
AXLE CASING STEEL VERSION
4
AXLE CASING STEEL VERSION
4
AXLE CASING CAST VERSION
4
AXLE CASING CAST VERSION
4
AXLE CASING CAST VERSION
4
AXLE CASING CAST VERSION
5
OUTSIDE GEAR ,V 207287V 496879 FROM REAR AXLE V 496880, SEE STANDARD MICROFICHE
5
OUTSIDE GEAR ,V 207286
5
OUTSIDE GEAR ,V 307324
5
OUTSIDE GEAR ,V 307324
5
OUTSIDE GEAR ,W 985139, V 000001V 207286
6
PLANETARY GEARING RATIO: 1:3.947,W 985138
6
PLANETARY GEARING , Replaced By: A3463504709
6
PLANETARY GEARING RATIO: 1:3.966,V 207286
6
PLANETARY GEARING RATIO: 1:3.966,W 985139, V 000001
6
PLANETARY GEARING RATIO: 1:3.947,W 985138
6
PLANETARY GEARING RATIO: 1:4.000,V 207287
6
PLANETARY GEARING1:3.429,V 307324
6
PLANETARY GEARING , Replaced By: A3463504609
6
PLANETARY GEARING RATIO: 1:3.472,W 985139, V 000001V 307323
6
PLANETARY GEARING RATIO: 1:3.472
6
PLANETARY GEARING RATIO: 1:3.478,W 985138
6
PLANETARY GEARING RATIO: 1:3.478,W 985138
6
PLANETARY GEARING RATIO: 1:3.478,W 985138
6
PLANETARY GEARING RATIO: 1:3.478,W 985138
9
BELL HUB , Replaced By: A3463508033
9
BELL HUB WITH PLANETARY CARRIER,V 049844
9
BELL HUB WITH PLANETARY CARRIER,V 207286
9
BELL HUB WITH PLANETARY CARRIER,569982
9
BELL HUB WITH PLANETARY CARRIER,V 207287
9
BELL HUB WITH PLANETARY CARRIER,V 307324
9
BELL HUB , Replaced By: A3463507933
9
BELL HUB , Replaced By: A3463501909
9
BELL HUB WITH PLANETARY CARRIER,V 049844V 307323
9
BELL HUB WITH PLANETARY CARRIER,W 985139, V 000001W 999999, V 049843
9
PLANETARY GEARING RATIO: 1:3.472
9
BELL HUB WITH PLANETARY CARRIER
18
SCREW MAIN TRANSMISSION PLANETARY GEAR SET ON PLANETARY GEAR TRAIN
18
SCREW MAIN TRANSMISSION PLANETARY GEAR SET ON PLANETARY GEAR TRAIN
20
PART NAME MISSING SET50 PIECES,W 985139, V 000001V 496879 FROM REAR AXLE V 496880, SEE STANDARD MICROFICHE
20
NEEDLE BEARING NEEDLES, SET50 PIECES
22
PLANET GEAR PARTS KIT,V 496484
22
PLANET GEAR PARTS KIT,W 985139, V 000001V 307323
22
PLANET GEAR PARTS KIT
22
PLANET GEAR PARTS KIT,V 207286
22
PLANET GEAR PARTS KIT
27
SCREW SUPPORT TO JOINT HOUSING M 14X35
29
REAR AXLE SHAFT WITH INTERLOCK SERRATIONS,W 972499
29
REAR AXLE SHAFT
29
REAR AXLE SHAFT , Replaced By: A6583570701, +001N009045050001
29
REAR AXLE SHAFT , Replaced By: A6583570601, +001N009045050001
31
SUN GEAR NUMBER OF TEETH: 25,V 207287V 496879 FROM REAR AXLE V 496880, SEE STANDARD MICROFICHE
31
SUN GEAR NUMBER OF TEETH: 35,V 307324V 496879 FROM REAR AXLE V 496880, SEE STANDARD MICROFICHE
31
SUN GEAR NUMBER OF TEETH: 29,W 985139, V 000001V 207287
31
SUN GEAR NUMBER OF TEETH: 36,V 307323
31
SUN GEAR NUMBER OF TEETH: 25,V 207287
31
SUN GEAR NUMBER OF TEETH: 35,V 307324
31
SUN GEAR NUMBER OF TEETH: 29,W 985139, V 000001
31
SUN GEAR NUMBER OF TEETH: 36,W 985139, V 000001V 307323
33
END COVER ,006379 THIS NOTE OF REPLACEMENT APPLIES ONLY TO THE ITEM LISTED OPPOSITE, Replaced By: A3463340320, +002A3559970232, +002N007603045100
36
GASKET COVER TO BELL HUB, MAN AXLE
39
SCREW COVER TO BELL HUB M 10X28
45
SCREW PLUG
45
SCREW PLUG , Replaced By: A2109970132
51
SEALING RING. SEAL RING OIL DRAIN
999
OIL COLLECTOR
999
OUTSIDE GEAR NUMBER OF TEETH: 85
999
OUTSIDE GEAR PLANETARY GEAR TRAIN,NUMBER OF TEETH: 89,W 972500, V 000001V 207323
999
BELL HUB
999
BELL HUB
999
BELL HUB WITH PLANETARY CARRIER
999
BELL HUB , Replaced By: A3463507433
999
BELL HUB
999
BELL HUB ,V 049844
999
PLANETARY GEARING RATIO: 1:3.429,V 496484
999
BELL HUB
999
BELL HUB
999
BELL HUB
999
PLANETARY GEARING
999
PLANETARY GEARING RATIO: 1:3.429
999
PLANETARY GEARING
999
PLANETARY GEARING RATIO: 1:3.472,W 972500, V 000001V 207323
999
BELL HUB WITH PLANETARY CARRIER,V 156242
999
PLANETARY GEARING
999
PLANETARY GEARING
999
BRAKE DRUM220MM
999
PROTECTIVE PLATE WITHOUT BEAD AND ABS,WITH BRAKE LINING WEAR INDICATOR
999
PROTECTIVE PLATE WITH BEAD,A B S AND BRAKE LINING WEAR INDICATOR
999
PROTECTIVE PLATE ABS AND BRAKE LINING WEAR INDICATOR
999
PROTECTIVE PLATE WITH BEAD,A B S AND BRAKE LINING WEAR INDICATOR
999
PROTECTIVE PLATE ABS AND BRAKE LINING WEAR INDICATOR
999
BRAKE SHOE , FIRST EXHAUST STOCK OF OLD PARTS UP TO REAR AXLE 740./748. W981677 / 744./745. N 029070, Replaced By: A6244200219
999
WHEEL HUB
999
BRAKE SHOE , FIRST EXHAUST STOCK OF OLD PARTS UP TO REAR AXLE W 983960 ONLY USE CAST-IRON OR SHEET-IRON BRAKE SHOES AT THE SAME TIME ON ONE AXLE, Replaced By: A3894206419
999
BRAKE DRUM
999
BRAKE DRUM
999
WHEEL MOUNTING BOLT LIGHT-ALLOY-SHEET DISC WHEEL, Replaced By: A0004013771
999
WHEEL MOUNTING BOLT DISC WHEEL TO REAR DRUM HUB M 22X1.5X105, Replaced By: A0004013871
999
PROTECTIVE PLATE , Replaced By: A6954200044
999
PROTECTIVE PLATE , Replaced By: A6954200044
999
WHEEL HUB
999
WHEEL HUB
999
WHEEL HUB
999
BELL HUB ,V 049844V 307323
999
BELL HUB , Replaced By: A3553505033
999
BELL HUB
999
PLANETARY GEARING RATIO:,W 972499
999
PLANETARY GEARING
999
PLANETARY GEARING
999
SPRING
999
THRUST SHACKLE
999
REAR AXLE SHAFT , Replaced By: A6583570901, +001N009045050001
999
REAR AXLE SHAFT , Replaced By: A6583570801, +001N009045050001
999
WHEEL HUB
