Поз.
Артикул
Описание
6
TANK OIL
6
TANK , Replaced By: A0004664502
7
PIPETO 000 466 38 02
8
OIL DIPSTICK
8
OIL DIPSTICK , Replaced By: A0004660867
9
COVERTO 000 466 38 02
10
FILLER CAP
11
SEAL RINGTO 000 466 38 02
12
SEAL RING
13
FILTER CARRIERTO 000 466 38 02
14
BRACKET
15
FILTER
15
FILTER , Replaced By: A0004660604
16
SEALING CORD , Replaced By: A0059970848
16
SEAL RING , Replaced By: A0059970848
16
SEAL RINGTO 000 466 38 02
17
CONNECTORTO 000 466 38 02
18
NUTTO 000 466 38 02
19
CENTERING RINGTO 000 466 38 02
20
SPACER WASHERTO 000 466 38 02
20
WASHER , Replaced By: A9402680552
21
SPACER TUBETO 000 466 38 02
22
COVER PLATETO 000 466 38 02
23
RUBBER SLEEVETO 000 466 38 02
24
SCREW OIL TANK TO BRACKET
24
HEXALOBULAR BOLT WIRE CABLE TO BRACKET
24
SCREW , Replaced By: N000000001149
24
SCREW , Replaced By: A0029903712
25
NUT , Replaced By: N913002006009
25
NUT , Replaced By: N913004006001
25
NUT PUMP TO BRACKET
25
NUT OIL TANK TO BRACKET
30
BRACKET OIL TANK
30
BRACKET OIL TANK
40
LOCK WASHER BRACKET TO SUPPORT AND TO END PIECE
42
HEXAGON HEAD BOLT BRACKET TO TRANSMISSION
50
LINE (DELIVERY LINE) FROM HIGH PRESSURE HOSE TO FITTING
50
LINE HIGH PRESSURE HOSE,CONNECTOR,STEERING
50
LINE , NOT USED
55
SEAL CONE LINE CONNECTION
55
GLAND , Replaced By: A0019901967
57
UNION NUT LINE CONNECTION, Replaced By: N000000006239
65
HOSE (DELIVERY LINE),FROM PUMP TO STEERING
65
HOSE (DELIVERY LINE),FROM PUMP TO STEERING
65
HOSE (DELIVERY LINE),FROM PUMP TO STEERING
67
TUBE FROM HIGH PRESSURE HOSE TO STEERING
67
LINE FROM PUMP TO HIGH PRESSURE HOSE
67
LINE , Replaced By: A0005516156
68
GLAND , Replaced By: A0019901967
68
SEAL CONE LINE CONNECTION
69
UNION NUT LINE CONNECTION, Replaced By: N000000006239
70
SCREW-IN FITTING DELIVERY LINE TO PUMP
75
HOSE , NOT USED
75
HOSE , Replaced By: A6999974082
75
HOSE , Replaced By: A3439970582
75
HOSE , Replaced By: A3859971682
80
CLAMP HOSE TO FITTING AND TO OIL TANK
80
CLAMP HOSE TO FITTING AND TO OIL TANK 16-27X13 MM
85
LINE FROM STEERING TO OIL TANK
90
GLAND LINE CONNECTION
92
UNION NUT LINE CONNECTION
94
SCREW-IN FITTING RETURN, FROM STEERING TO OIL TANK
100
HOSE RETURN, FROM STEERING TO OIL TANK, ORDER BY THE METER
100
HOSE , Replaced By: A3859971582
105
CLAMP , Replaced By: N000000000667
105
CLAMP HOSE TO SUCTION LINE AND TO OIL TANK 20-32X13 MM
110
LINE FROM RETURN LINE TO OIL TANK, 620.415 UP TO IDENT NO. 5 014668 620.416 UP TO IDENT NO. 5 000515 620.417 UP TO IDENT NO. 4 972023
110
LINE FROM OIL TANK TO HOSE, NOT USED
112
LINE HOSE,CONNECTOR,STEERING
115
HOSE RETURN, FROM STEERING TO OIL TANK, ORDER BY THE METER
115
HOSE , Replaced By: A3859971582
120
CLAMP , Replaced By: N000000000667
120
CLAMP HOSE TO SUCTION LINE AND TO OIL TANK 20-32X13 MM
125
LINE FROM HOSE TO POWER STEERING PUMP
125
LINE FROM HOSE TO POWER STEERING PUMP
126
UNION NUT LINE CONNECTION, Replaced By: N000000006243
127
SEAL CONE LINE CONNECTION
127
GLAND , Replaced By: A0019901267
134
BRACKET , FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO. 4 716042, Replaced By: A3874660940
134
BRACKET DELIVERY AND SUCTION LINES TO FRAME
134
BRACKET DELIVERY AND SUCTION LINES TO BRACKET AT FRAME
144
SCREW SUPPORT TO SIDE MEMBER
146
NUT SUPPORT TO SIDE MEMBER
150
CLAMP DELIVERY AND SUCTION LINES TO ENGINE, FRONT
150
CLAMP DELIVERY AND SUCTION LINES TO ENGINE, TOP
155
CLAMP DELIVERY AND SUCTION LINES TO ENGINE, FRONT
155
CLAMP DELIVERY AND SUCTION LINES TO ENGINE, TOP
155
CLAMP DELIVERY AND SUCTION LINES TO ENGINE, TOP
158
SCREW DELIVERY AND SUCTION LINES TO ENGINE, TOP
160
NUT PUMP TO BRACKET
160
NUT , Replaced By: N913004006001
999
NEEDLE BEARING
999
PROTECTIVE CAP
999
BRACKET , EXHAUST STOCK OF OLD PARTS NUMBER FIRST UP TO CHASSIS 4 493018, Replaced By: A3812950440
999
COVER
999
BRACKET , Replaced By: A3812950440
999
STEERING SHAFT , Replaced By: A3814607109
999
STEERING SHAFT
999
RING STEERING SHAFT
999
SLEEVE STEERING SHAFT
999
COTTER PINROCKINGER TYP 260 G140
999
COTTER PINROCKINGER,TYP 260 G150,260 G140
999
WIRE STEERING BOX ASSEMBLY TO STEERING SUPPORT 600 MM
999
SHEET METAL SCREW PROTECTIVE SLEEVE TO CAB FLOOR,4 188586
