Поз.
Артикул
Описание
5
PLASTIC PIPE FUEL LINE 12X1,5 MM, ORDER BY THE METER
5
HOSE , Replaced By: A0009872827
8
BUSHING , Replaced By: N915062009000
8
SLEEVE LINE CONNECTION
10
UNION NUT , Replaced By: N915017012100
10
UNION NUT LINE CONNECTION, Replaced By: N000000006239
10
UNION NUT LINE CONNECTION
12
GLAND , Replaced By: A0019901967
12
SEAL CONE LINE CONNECTION
14
BANJO UNION , Replaced By: N915052009009
14
BANJO UNION HOSE WIDTH, / I.D., 9/16 MM
16
PLASTIC PIPE. HOSE AERATION 6X8 MM, ORDER BY THE METER
18
GLAND LINE CONNECTION
20
UNION NUT LINE CONNECTION
20
UNION NUT , Replaced By: N915017008100
22
SLEEVE LINE CONNECTION
24
BANJO UNION , Replaced By: N915052006002
24
BANJO UNION HOSE WIDTH, / I.D., 6/16 MM
26
LOOM TIE LINE MOUNTING
28
T-FITTING LOAD/NO-LOAD VALVE, 620.415 UP TO CHASSIS 5 014668 620.416 UP TO CHASSIS 5 000515 620.417 UP TO CHASSIS 4 972023
30
ELBOW FITTING DELIVERY LINE TO PUMP
30
FITTING DELIVERY LINE TO PUMP
31
ELBOW FITTING DELIVERY LINE TO PUMP
32
T-FITTING LOAD/NO-LOAD VALVE, 620.415 UP TO CHASSIS 5 014668 620.416 UP TO CHASSIS 5 000515 620.417 UP TO CHASSIS 4 972023
34
T-FITTING
37
BRAKE VALVE (TRAILER CONTROL VALVE) "BOSCH"
39
REPAIR KIT TRAILER CONTROL VALVE TO 001 431 46 05,BOSCH
40
ELBOW FITTING AIR RESERVOIR,CONNECTIONS: "31,32"
43
ELBOW FITTING COMBINATION CYLINDER,CONNECTION: "12"
43
ELBOW FITTING , Replaced By: A0004294638
46
O-RING CHECK VALVE TO AIR RESERVOIR
49
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940203
49
THRUST RING CHECK VALVE TO AIR RESERVOIR
52
NUT CHECK VALVE TO AIR RESERVOIR
55
NUT STRAP TO BRACKET
55
NUT , Replaced By: N910113010000
58
BRACKET TRAILER CONTROL VALVE
59
BRACKET TRAILER CONTROL VALVE
60
FITTING REAR AXLE REGULATING SOLENOID VALVE, CONNECTIONS: "10"
61
FITTING REAR AXLE REGULATING SOLENOID VALVE, CONNECTIONS: "10"
61
HOLLOW SCREW FRONT AXLE REGULATING SOLENOID VALVE, CONNECTION: "10",K 009079
62
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
63
SCREW CONSOLE TO SIDE MEMBER
64
NUT SUPPORT TO SIDE MEMBER
65
SCREW BRAKE LINE COUPLING TO REAR CROSS MEMBER
66
NUT COMBINATION CYLINDER TO BEARING BRACKET
66
NUT SUPPORT TO SIDE MEMBER
66
NUT COMBINATION CYLINDER TO BEARING BRACKET, Replaced By: N910113016002
67
WASHER
69
BRAKE LINE COUPLING AT REAR CROSS MENBER
71
BRAKE LINE COUPLING AT REAR CROSS MENBER
71
BRAKE LINE COUPLING , Replaced By: A0004297530
73
BRAKE LINE COUPLING , Replaced By: A0004297530
75
BRAKE LINE COUPLING AT REAR CROSS MENBER
77
VALVE DISCTO 000 429 48 30
79
VALVE DISCTO 000 429 48 30
81
SPRINGTO 000 429 16 30
83
VALVE PARTTO 000 429 16 30
85
GASKETTO 000 429 16 30
88
NUTTO 000 429 16 30
91
VALVE TAPPETTO 000 429 16 30
94
SNAP RINGTO 000 429 16 30
97
COVERTO 000 429 16 30,BOSCH
98
COTTER PIN DRAG LINK TO STEERING ARM AND PITMAN ARM
101
SPRINGTO 000 429 16 30
104
SPRING CAPSULETO 000 429 16 30
106
SEAL RINGTO 000 429 16 30
108
SEAL RINGTO 000 429 16 30
110
PIN
110
GASKET , Replaced By: A0004290184
112
COVERTO 000 429 48 30
114
COVERWABCO
116
VALVE CONEBOSCH
118
SEAL RINGTO 000 429 75 30
118
SEAL RINGBOSCH
122
SEAL RING LINE CONNECTION
124
FITTING SHUTTLE VALVE
124
FITTING , Replaced By: A0029971372
126
O-RING CHECK VALVE TO AIR RESERVOIR
128
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940203
128
THRUST RING CHECK VALVE TO AIR RESERVOIR
130
NUT BRACKET TO SIDE MEMBER
132
BRACKET AT BRAKE LINE COUPLING
132
BRACKET , Replaced By: A3854291540
132
BRACKET , FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO. 4 686340, Replaced By: A3184291640
134
SCREW , Replaced By: N304017008021
134
SCREW PIPE CLAMP
136
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
136
HEXAGON NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET
136
NUT , Replaced By: N913004008001
139
VALVE , THIS NOTE OF REPLACEMENT APPLIES ONLY TO THE ITEM LISTED OPPOSITE, Replaced By: A0024299544
139
VALVE TWO-WAY VOSS
142
VALVE BODYTO 002 429 95 44
142
VALVE , Replaced By: A0004290782
142
VALVE , Replaced By: A0004291182
144
BALLTO 003 429 22 44
146
GASKETTO 003 429 22 44
148
T-FITTING RELAY VALVE,CONNECTION: "12"
150
NUT CHECK VALVE TO AIR RESERVOIR
152
THRUST RING CHECK VALVE TO AIR RESERVOIR
152
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940203
154
O-RING CHECK VALVE TO AIR RESERVOIR
156
TEST CONNECTION
156
TEST CONNECTION SOLENOID VALVE,CONNECTION: "20"
156
TEST CONNECTION SOLENOID VALVE,CONNECTION: "20"
156
TEST CONNECTION SOLENOID VALVE,CONNECTION: "20"
157
PLUG
158
FITTING REAR AXLE REGULATING SOLENOID VALVE, CONNECTIONS: "10"
160
SEAL RING LINE CONNECTION
162
T-FITTING TWO-WAY VALVE,CONNECTION "1.2"
164
NUT LOAD/NO-LOAD VALVE,CONNECTIONS: "10,20"
166
THRUST RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
168
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
168
SEAL RING
170
TEST CONNECTION
170
TEST CONNECTION SOLENOID VALVE,CONNECTION: "20"
170
TEST CONNECTION SOLENOID VALVE,CONNECTION: "20"
170
TEST CONNECTION SOLENOID VALVE,CONNECTION: "20"
171
PLUG
172
HOLLOW SCREW LINE TO OIL RADIATOR
173
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
175
NUT CHECK VALVE TO AIR RESERVOIR
179
THRUST RING CHECK VALVE TO AIR RESERVOIR
179
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940203
182
O-RING CHECK VALVE TO AIR RESERVOIR
999
REPAIR KITKNORR
999
REPAIR KITWABCO
999
HOLLOW SCREW , Replaced By: N915036012101
