Поз.
Артикул
Описание
605
PUMP PRIMING FUEL
610
NUT
615
HANDLE
620
SEAL CONE REPAIR KIT
625
SCREW CONNECTION
630
WASHER STARTER PILOT PUMP
640
PRIMER CAPSULE PRIMING FUEL
645
SERRATED WASHER
650
NUT
655
NUT REPAIR KIT
660
FILLING CYLINDER PRIMING FUEL
665
BRACKET PRIMER CAPSULE
670
SCREW , Replaced By: N000000001146
670
SCREW CLAMP MOUNTING M 6X16
675
NUT , Replaced By: N913004006001
675
NUT PUMP TO BRACKET
680
HOSE FUEL LINE, ORDER BY THE METER
680
HOSE FUEL LINE, ORDER BY THE METER
680
HOSE FUEL LINE, ORDER BY THE METER
685
LOOM TIE LINE MOUNTING
690
GROMMET
999
VALVE , Replaced By: A0005501555
999
PUMP , FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO. 5 162440, Replaced By: A0005502383
999
PRIMER CAPSULE , Replaced By: A0005501404
999
VALVETO 000 553 23 01,000 553 37 01,
999
FITTING
999
PUMP , Replaced By: A0005537901
999
PUMP , Replaced By: A0005536801
999
HANDLE , Replaced By: A0005550440
999
REPAIR KIT , Replaced By: A0005501235
999
SCREW , Replaced By: A0009901310
999
SCREW OIL FILLING TO 000 553 89 01
999
NUT , Replaced By: A0009949454
999
SEAL CONE , Replaced By: A0009949454
999
SEAL CONE , Replaced By: A0005550618
999
GASKET KIT , Replaced By: A0005502583
999
BRACKET , EXHAUST STOCK OF OLD PARTS NUMBER FIRST UP TO CHASSIS 4 493018, Replaced By: A3812950440
999
SEAL RING , THE OLD PART MUST NO LONGER BE INSTALLED THIS NOTE OF REPLACEMENT APPLIES ONLY TO THE ITEM LISTED OPPOSITE, Replaced By: A6208910017
999
SEAL RING , THE OLD PART MUST NO LONGER BE INSTALLED THIS NOTE OF REPLACEMENT APPLIES ONLY TO THE ITEM LISTED OPPOSITE, Replaced By: A6208910017
999
FITTING , Replaced By: A0019909871
