Поз.
Артикул
Описание
8
HOUSING OIL FILTER,OIL COOLER, 422 - 122785 423.950 149717
8
HOUSING , 422.901-500-122674 424.901-500-001979, Replaced By: A4221880404, +001A3522036439, +002N000137008204, +002N000933008147, +001N917003022003
9
BAFFLE PLATE , Replaced By: A0001880209
9
BAFFLE PLATE BAFFLE PLATE TO OIL COOLER HOUSING
10
SCREW COVER PLATE TO COVER PLATE M 6 X 10
10
SCREW , Replaced By: N304017006034
20
COVER OIL COOLER
23
SCREW PLUG
23
SCREW PLUG , Replaced By: A2109970132
26
SEALING RING. SEAL RING OIL DRAIN
35
GASKET OIL COOLER COVER TO AUXILIARY OIL COOLER HOUSING
38
HEXALOBULAR BOLT. SCREW SUPPORT TO CYLINDER HEAD
38
HEXAGON HEAD BOLT. SCREW CABLE HARNESS TO BRACKET M8X40
41
WASHER BRACKET TO CROSS MEMBER
74
FILTER BOWL OIL FILTER BOWL
80
SCREW PLUG SHIFTING SHAFT DETENT
80
SCREW PLUG , Replaced By: A4429970030
83
SEAL RING VALVE TO VALVE,K 025179
86
FILTER ELEMENT RANGE OF DELIVERY
86
FILTER ELEMENT , Replaced By: A4021800009
92
SEAL RING FILTER BOWL TO FILTER HEAD
95
SEAL RING FUEL LINE TO FEED PUMP
104
SCREW
110
VALVE
110
VALVE , Replaced By: A4031840132
113
SPRING BY-PASS VALVE
116
SCREW PLUG
119
SEAL RING AIR COMPRESSOR,CONNECTION: "10"
122
SCREW PLUG
122
SCREW PLUG
128
SCREW PLUGROCKINGER TYP 59 G140,59 G150, Replaced By: N007604012105
128
SCREW PLUGROCKINGER,TYP 59 U150
134
SEAL RING PRESSURE REGULATOR,CONNECTION: "23",5 161701
137
OIL COOLER
140
OIL COOLER
143
SEAL. GASKET , Replaced By: A3661880880
143
GASKET , Replaced By: A4421880380
143
GASKET , Replaced By: N917003026003
143
GASKET OIL COOLER TO OIL FILTER HEAD,TOP
144
GASKET HEATING PIPE TO ENGINE
146
SCREW. CAP BOLT SEAT MOUNTING M8X35
146
SCREWM 8X60
146
SCREW SPRING STOP
146
SCREW , Replaced By: N000912008204
149
WASHER BRACKET TO CROSS MEMBER
152
GASKET OIL FILTER HEAD & OIL COOLER COVER WITH OIL COOLER TO CRANKCASE
152
GASKET , Replaced By: A4421880280
152
GASKET , Replaced By: A4421880580
155
SCREW , Replaced By: N000931010462
155
SCREW , Replaced By: N304017010047
155
SCREW BRACKET TO SIDE MEMBER M10X35
155
SCREW SPARE WHEEL HOIST TO CROSS MEMBER M 10X120
155
SCREW CLUTCH SLAVE CYLINDER TO BELL HOUSING M 10X170
155
HEXAGON HEAD BOLT BRACKET TO BRACKET M10X35
158
SPRING WASHER STEERING COLUMN BRACKET TO CAB
999
GASKET , Replaced By: A4421880480
