Поз.
Артикул
Описание
170
PLASTIC PIPE. HOSE AERATION 6X8 MM, ORDER BY THE METER
172
FITTING (PARTS KIT),LINE RUPTURE
172
FITTING , Replaced By: A0029905971
174
UNION NUT LINE CONNECTION, Replaced By: N000000006239
174
UNION NUT LINE CONNECTION
174
UNION NUT LINE CONNECTION
176
GLAND LINE CONNECTION
176
SEAL CONE LINE CONNECTION
176
GLAND , Replaced By: A0019901967
178
SLEEVE LINE CONNECTION
178
SLEEVE LINE CONNECTION
180
BANJO UNION HOSE WIDTH, / I.D., 6/12 MM
180
BANJO UNION HOSE WIDTH, / I.D., 6/16 MM
182
T-FITTING EXHAUST BRAKE LINE CONNECTION
183
LOOM TIE LINE MOUNTING
183
LOOM TIE LINE MOUNTING 280 MM
184
ANGLE LINE MOUNTING
186
BRACKET COMPRESSED AIR LINE TO FOUR-CIRCUIT PROTECTIVE VALVE,5 720506
186
BRACKET , Replaced By: A3812950440
188
BRACKET (T-FITTING) EXHAUST BRAKE LINE CONNECTION
190
CLAMP DELIVERY AND SUCTION LINES TO STEERING
190
CLAMP , Replaced By: A6739950001
192
WASHER COMPRESSED AIR LINE TO BRACKET, Replaced By: N000125006449
192
WASHER COMPRESSED AIR LINE TO BRACKET
192
WASHER BRACKET TO LEFT SIDE MEMBER
194
SCREW BRACKET TO APPARATUS SUPPORT M 6X16
196
SCREW CLAMP TO BRACKET
196
SCREW CLAMP TO BRACKET, Replaced By: N007985006581
198
NUT , Replaced By: N913004006001
198
NUT PUMP TO BRACKET
999
FITTING LOAD/NO-LOAD VALVE,CONNECTION: "20",5 727400
