Поз.
Артикул
Описание
12
RUBBER MOUNTING
12
RUBBER MOUNTING FRONT
12
RUBBER MOUNTING FRONT
12
RUBBER MOUNTING ADJUSTABLE,FRONMT
12
RUBBER MOUNTING ADJUSTABLE,FRONMT
19
BEARING BRACKET LEFT AND RIGHT
26
SCREW DELIVERY AND SUCTION LINES TO FRAME M 12X40
26
SCREW DELIVERY AND SUCTION LINES TO FRAME M 12X35
26
SCREW , Replaced By: N308676012026
26
SCREW SUPPORT TO SIDE MEMBER
26
SCREW , Replaced By: N000961012025
33
WASHER MOUNTING USED FOR FRAME CONNECTION PARTS
40
LOCK WASHER FITTING TO BRACKET
47
NUT SUPPORT TO SIDE MEMBER
47
NUT SUPPORT TO SIDE MEMBER
54
SCREW RUBBER MOUNTING TO SUPPORTING ARM M 16X1.5X38
61
WASHER CONSOLE TO FRAME
68
RUBBER MOUNTING REAR
68
RUBBER MOUNTING REAR
68
RUBBER MOUNTING REAR
75
SCREW DELIVERY AND SUCTION LINES TO FRAME M 12X35
75
SCREW , Replaced By: N308676012026
75
SCREW CONSOLE TO SIDE MEMBER
82
WASHER
89
SCREW SUPPORTING ARM TO BELL HOUSING
89
SCREW , Replaced By: N308676018001
