Поз.
Артикул
Описание
7
CROSS MEMBERNO.3A
14
STRUT LEFT AND RIGHT
21
SCREW , Replaced By: A9429901304
21
SCREW APPARATUS SUPPORT TO FRAME
21
SCREW APPARATUS SUPPORT TO FRAME
21
SCREW APPARATUS SUPPORT TO FRAME
28
NUT , Replaced By: N910113014000
28
NUT STEERING SUPPORT TO FRAME
28
NUT STEERING SUPPORT TO FRAME
28
NUT STEERING SUPPORT TO FRAME
28
NUT STEERING SUPPORT TO FRAME
35
WASHER , Replaced By: N000125015019
35
WASHER STRUT TO EXHAUST PIPE AND TO SIDE MEMBER
35
WASHER STRUT TO EXHAUST PIPE AND TO SIDE MEMBER
35
WASHER STRUT TO EXHAUST PIPE AND TO SIDE MEMBER
35
WASHER STRUT TO EXHAUST PIPE AND TO SIDE MEMBER
42
SCREW , Replaced By: N308676014012
42
SCREW SUPPORT TO SIDE MEMBER M 14X45
49
SCREW BRACKET TO FRAME M 12X35
56
NUT , Replaced By: N910113012003
56
HEXAGON NUT EXHAUST PIPE TO BRACKET ON SIDE MEMBER
