Поз.
Артикул
Описание
233
VALVE 2/2 -WAY VALVE
233
VALVE THREE-WAY VALVE
233
VALVE , Replaced By: A0038305784
233
VALVE , Replaced By: A0038305684
233
VALVE 2/2 -WAY VALVE, Replaced By: A0048301884
233
VALVE THREE-WAY VALVE, Replaced By: A0048301684
236
ELECTRIC MOTOR , Replaced By: A0068207842
236
SERVO-D.C. W.GEARBOX
248
HOSE18X27X100MM
248
HOSE SILICONE 18 X 27 X 275 MM, TO BE ADAPTED DURING ASSEMBLY
248
HOSE FROM BUBBLE SEPARATOR TO HEATING PIPE 18X27 MM, ORDER BY THE METER
248
HOSE18X27X80MM, TO BE ADAPTED DURING ASSEMBLY
248
HOSE I.D., 18 MM
251
HOSE AIR COMPRESSOR CONNECTION 240 MM, ORDER BY THE METER
251
CAP EXPANSION TANK
251
HOSE SILICONE 22 X 31 X160 MM, TO BE ADAPTED DURING ASSEMBLY
254
HOSE FROM WATER PUMP TO EXPANSION TANK 28X37X80,5 022370 ORDER BY THE METER
254
HOSEA28, B37, L100
254
HOSE
257
HOSE CONNECTION OF OIL FILLER PIPES, ORDER BY THE METER
257
HOSEA38, B50, L100
260
CLAMP35.6-37.3 MM
260
CLAMP29.5-31 MM
260
CLAMP26-27.5 MM
260
CLAMP HOSE TO INTAKE MANIFOLD 25-40X13MM,V 207570
260
CLAMP HOSE TO SUCTION LINE AND TO OIL TANK 20-32X13 MM
260
CLAMP25-40X13 MM
260
CLAMP
260
CLAMP HOSE FASTENING 50-70X13 MM
266
CLAMP FRAME MOUNTED CABLE HARNESS AND BATTERY CABLE TO BRACKET
266
CLAMP DELIVERY AND SUCTION LINES TO FRAME, Replaced By: N916016022203
266
CLAMP CABLE HARNESS MOUNTING
266
CLAMP , Replaced By: A3829950101
266
CLAMP CLAMP TO CROSS MEMBER 42/20
266
CLAMP SAFETY VALVE AT BRACKET
266
CLAMP
266
CLAMP LINE MOUNTING
266
CLAMP DELIVERY AND SUCTION LINES TO FRAME
266
CLAMP HOSE TO BRACKET 25/20,5 206397
266
CLAMP BRAKE HOSE BRACKET
284
PIPE LINE ENGINE COMPARTMENT
287
PIPE LINE ENGINE COMPARTMENT
289
PIPE LINE FEED 1580 MM
292
PIPE LINE FEED TO ROOF MOUNTED HEAT EXCHANGER
295
PIPE LINE BEHIND CENTRAL AXLE
298
PIPE LINE BEHIND CENTRAL AXLE
301
PIPE LINE BEHIND REAR AXLE
304
PIPE LINE BEHIND REAR AXLE
307
PIPE LINE BEHIND REAR AXLE
310
PIPE LINE BEHIND REAR AXLE
313
PIPE LINE BEHIND REAR AXLE
316
PIPE LINE BEHIND REAR AXLE
319
PIPE LINE BEHIND REAR AXLE
322
PIPE LINE BEHIND REAR AXLE
325
PIPE LINE BEHIND REAR AXLE
331
PIPE LINE BEHIND REAR AXLE
334
PIPE LINE BEHIND REAR AXLE
999
VALVE HEATING CONTROL
