Поз.
Артикул
Описание
5
BRAKE VALVE
5
BRAKE VALVE ,104816
5
BRAKE VALVE ,104815
8
MUFFLER TRAILER CONTROL VALVE
11
THRUST RING CHECK VALVE TO AIR RESERVOIR
14
O-RING CHECK VALVE TO AIR RESERVOIR
17
NUT HORN TO BRACKET M8
20
DISTRIBUTOR REAR AXLE
23
SCREW SHIFT LEVER TO BRACKET M8X30
23
SCREW. HEXALOBULAR BOLT MOUNTING FRAME TO SUPPORT M 8X30
26
SPACER BUSH15X9X11LG.
29
NUT HORN TO BRACKET M8
32
HOSE BRAKE VALVE BLEEDING TO VOSS 232, ORDER BY THE METER FROM IDENT NO. WEB 105309 ALSO INSTALLED ON 104831-104930,104931-105130,105261,105268-105295,105307. EXCEPT 105317,105318,105324,105382,105388. FROM IDENT NO. VF9 300289 ALSO INSTALLED ON 300046,300282-300284.
35
CLAMP HOSE TO FITTING 11 - 20 MM
35
CLAMP HOSE TO FITTING AND TO OIL TANK 16-27X13 MM
35
CLAMP HOSE TO RADIATOR AND TO EXPANSION TANK 12-22X13 MM
38
ELBOW FITTING COMPRESSED-AIR-LINE PLUG-CONNECTION TO M 22, 12 MM, VOSS 230
50
AXLE MODULATOR REAR AXLE VOSS 232
50
AXLE MODULATOR REAR AXLE EPB, REPAIR IMPOSSIBLE
53
HEXAGON HEAD BOLT BRACKET TO SIDE MEMBER M12X1.5X35
56
FITTINGM18X1.5/M16X1.5 RAUFOSS
59
REDUCTION FITTING. THREADED UNION WITH O-RING M22X1.5/M16X1.5 RAUFOSS
62
T-FITTINGM16X1.5/M16X1.5/M16X1.5
65
FITTINGM 16X1.5
65
FITTINGNG12/M16X1.5
68
THRUST RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
71
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
77
80
83
86
UNION NUTAL12
89
CUTTING RINGS12
92
BULKHEAD FITTING FROM BRAKE VALVE,CONNECTION "21",TO FITTING
95
SERRATED WASHERA19
98
NUT BRACKET TO SIDE MEMBER
161
FITTINGM16X1.5/M16X1.5 RAUFOSS
