Поз.
Артикул
Описание
24
BRACKET LINE MOUNTING
27
SCREW BRACKET TO SUPPORT M 16X16
27
SCREW BRACKET TO SUPPORT M 16X20
41
HOSE , Replaced By: A0009872827
41
PLASTIC PIPE FUEL LINE 12X1,5 MM, ORDER BY THE METER
44
FITTING (PARTS KIT),LINE RUPTURE
47
BANJO UNION HOSE WIDTH, / I.D., 9/16 MM
50
INSULATING HOSE AIR DEHYDRATOR, ORDER BY THE METER
53
CONNECTOR , Replaced By: A0019903978
53
CONNECTOR DISTRIBUTOR TO FRAME
54
CONNECTOR HOSE WIDTH, 9 MM,TO M22
56
CONNECTOR DISTRIBUTOR TO CAB
59
CONNECTOR DISTRIBUTOR TO CAB
59
CONNECTOR DISTRIBUTOR TO CAB
62
CONNECTOR DISTRIBUTOR TO FRAME
65
CONNECTOR DISTRIBUTOR TO FRAME
68
CONNECTOR DISTRIBUTOR TO CAB
74
SEAL RING , Replaced By: A0229973948
74
SEAL RING CONNECTOR 11.8X2 MM
74
SEAL RING
75
PLUG EXHAUST BRAKE VALVE, CONNECTION: "20"
76
NUT EXHAUST BRAKE VALVE, CONNECTION: "20"
77
SCREW , Replaced By: N308676012012
77
SCREW. HEXAGON HEAD BOLT VALVE TO BRACKET
80
NUT , Replaced By: N910113012003
80
HEXAGON NUT EXHAUST PIPE TO BRACKET ON SIDE MEMBER
83
BRACKET CONNECTOR TO FRAME
86
SCREW DELIVERY AND SUCTION LINES TO ENGINE, FRONT M 6X35
89
NUT , Replaced By: N913004006001
89
NUT PUMP TO BRACKET
92
SCREW EXHAUST BRAKE SEPARATION POINT
95
DISTRIBUTOR LINE CONNECTION
96
T-FITTING COMPRESSED-AIR-LINE PLUG-CONNECTION TO M 22, M 12X1.5 MM/ 9 MM
101
T-FITTING COMPRESSED-AIR-LINE PLUG-CONNECTION TO M 22
104
ELBOW FITTING HOSE WIDTH, 9 MM,TO M 22
107
ELBOW FITTING COMPRESSED-AIR-LINE PLUG-CONNECTION
108
ELBOW FITTING COMPRESSED-AIR-LINE PLUG-CONNECTION TO M 22, 9 MM
110
ELBOW FITTING HOSE WIDTH, 9 MM,TO M 22
113
CONNECTOR HOSE WIDTH, 9 MM,TO M 22
113
CONNECTOR HOSE WIDTH, 6 MM, TO M22
114
CONNECTOR HOSE WIDTH, 9 MM,TO M 22
119
SEAL RING COMPRESSED-AIR-LINE PLUG-CONNECTION
122
LOCK COMPRESSED-AIR-LINE PLUG-CONNECTION
125
REPAIR KIT. TS SEALING RING COMPRESSED-AIR-LINE PLUG-CONNECTION TO M 22
