Поз.
Артикул
Описание
5
PRESSURE REGULATORWABCO
5
PRESSURE REGULATORBOSCH,241, PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
5
PRESSURE REGULATORBOSCH, PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART, Replaced By: A0034313606
5
PRESSURE REGULATORWABCO, Replaced By: A0034313806
5
PRESSURE REGULATORKNORR
8
REPAIR KIT DIAPHRAGM PART BOSCH,209
8
REPAIR KIT SEAL RING BOSCH,209
8
REPAIR KIT PRESSURE REGULATOR WABCO
8
REPAIR KIT PRESSURE REGULATOR BOSCH,241
8
REPAIR KIT PRESSURE REGULATOR KNORR
11
SCREW FRONT AXLE REGULATING SOLENOID VALVE
11
SCREW , Replaced By: N000933008134
14
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
14
NUT , Replaced By: N913004008001
14
HEXAGON NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET
17
BRACKET PRESSURE REGULATOR
20
SCREW END PIECE TO EXHAUST PIPE M 10X25
23
NUT STRAP TO BRACKET
23
NUT , Replaced By: N910113010000
26
FITTING AIR DEHYDRATOR,CONNECTION: "10",5 433280
27
CONNECTOR PRESSURE REGULATOR,CONNECTION: "40"
29
SEAL RING LOAD/NO-LOAD VALVE,CONNECTIONS: "20,21",5 727400
41
HOLLOW SCREW HEATING CONNECTION
44
SEAL RING LINE CONNECTION
47
HOSE PRESSURE REGULATOR,CONNECTION: "30", ORDER BY THE METER
50
CLAMP HOSE TO SUCTION LINE AND TO OIL TANK 20-32X13 MM
50
CLAMP , Replaced By: N000000000667
53
AIR DEHYDRATORWABCO,5 9375855 937586 PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART, Replaced By: A0014312215, +001A0004292139
53
AIR DEHYDRATORKNORR,5 937586, Replaced By: A0024317015
53
AIR DEHYDRATORWABCO,5 937586 PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
53
AIR DRIERKNORR,5 937586
53
AIR DEHYDRATORBOSCH,5 937586
56
AIR CLEANER COMPLETE TO BOSCH,KNORR
56
AIR CLEANER COMPLETE KNECHT:TO BOSCH,KNORR
59
SEAL RINGWABCO
62
GASKET KITWABCO
65
SCREW. HEXAGON HEAD BOLT VALVE TO BRACKET
65
SCREW , Replaced By: N308676012012
71
LOCK WASHER FITTING TO BRACKET
80
BRACKET AIR DEHYDRATOR,5 433281
83
SCREW BRACKET TO SIDE MEMBER
83
SCREW PIPE CLAMP
83
SCREW , Replaced By: N304017008021
86
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
86
NUT , Replaced By: N913004008001
86
NUT , Replaced By: N910113010000
86
HEXAGON NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET
86
NUT STRAP TO BRACKET
95
ELBOW FITTING ,5 433281
98
NUT CHECK VALVE TO AIR RESERVOIR
101
THRUST RING CHECK VALVE TO AIR RESERVOIR
101
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940203
104
O-RING CHECK VALVE TO AIR RESERVOIR
107
CONNECTOR BLEEDING
107
CONNECTOR 90 DEG. OFFSET
108
HOSE , Replaced By: A0009872927
108
PLASTIC PIPE FUEL LINE 16X2 MM, ORDER BY THE METER
110
SCREW. UNION SCREW LINE CONNECTION
113
SCREW. UNION SCREW LINE CONNECTION
113
SCREW. UNION SCREW , Replaced By: A0009973734
116
VALVE , Replaced By: A0034314706
116
VALVE (FOUR-CIRCUIT PROTECTIVE VALVE) BOSCH, PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART, Replaced By: A0034314106
116
VALVE (FOUR-CIRCUIT PROTECTIVE VALVE), PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
116
VALVE (FOUR-CIRCUIT PROTECTIVE VALVE) 260 0 WABCO
116
VALVE (FOUR-CIRCUIT PROTECTIVE VALVE) KNORR
116
VALVE (FOUR-CIRCUIT PROTECTIVE VALVE) GRAU, PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
119
REPAIR KIT FOUR-CIRCUIT PROTECTIVE VALVE
119
GASKET KIT FOUR-CIRCUIT PROTECTIVE VALVE
119
GASKET KIT FOUR-CIRCUIT PROTECTIVE VALVE GRAU,000 2
119
REPAIR KIT , Replaced By: A0004304706
122
SCREW , Replaced By: N304017008016
122
SCREW OIL-DIPSTICK GUIDE TUBE TO BRACKET
125
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
152
SCREW. UNION SCREW LINE CONNECTION
158
VALVE EMERGENCY RELEASE VALVE,CONNECTION: "23"
158
VALVE EMERGENCY RELEASE VALVE,CONNECTION: "23"
