Поз.
Артикул
Описание
288
BRACKET DEHYDRATOR AIR RESERVOIR,LEFT
289
BRACKET FROM CENTRAL AIR RESERVOIR TO T-FITTING
296
SCREW PROTECTIVE PLATE TO EXHAUST MUFFLER
296
SCREW REAR EXHAUST PIPE TO MUFFLER
296
SCREW , Replaced By: N304017010002
296
SCREW , Replaced By: N910105010009
296
SCREW BRACKET TO SIDE MEMBER
296
HEXAGON HEAD BOLT. SCREW BRACKET TO SIDE MEMBER M10X25
296
SCREW END PIECE TO EXHAUST PIPE M 10X25
304
NUT , Replaced By: N910113010000
304
NUT STRAP TO BRACKET
304
NUT EXHAUST PIPE TO SIDE MEMBER
310
WASHER , Replaced By: N000125010532
310
WASHER RADIATOR TO RUBBER MOUNTING
540
BATTERY SUPPORT
544
BATTERY CASE
548
BATTERY BASE FRAME
552
SPACER TUBE BATTERY BASE FRAME TO BATTERY/APPARATUS SUPPORT
552
SPACER TUBE BATTERY BASE FRAME TO BATTERY/APPARATUS SUPPORT
556
SCREW , Replaced By: N000000001441
556
HEXALOBULAR BOLT BATTERY BASE FRAME TO BATTERY/APPARATUS SUPPORT M 10X50
556
SCREW RADIATOR M 10X45
560
WASHER RADIATOR TO RUBBER MOUNTING
560
WASHER , Replaced By: N000125010532
999
SEAL RING LOAD/NO-LOAD VALVE,CONNECTIONS: "20,21",5 727400
999
BRACKET , Replaced By: A6205240340
999
BRACKET DEHYDRATOR AIR RESERVOIR,RIGHT L 100 MM, Replaced By: A6504312540
999
BRACKET DEHYDRATOR AIR RESERVOIR,LEFT
999
BASE AIR RESERVOIR STRAP
999
BRACKET AIR RESERVOIR TO CROSS MEMBER
999
STRAP CLUTCH BOOSTER AIR RESERVOIR 520 MM
999
BRACKET AT APPARATUS SUPPORT
999
BRACKET FUEL LINE TO BELL HOUSING
999
STRAP SPRING-LOADED BRAKE AIR RESERVOIR
999
BRACKET AIR DEHYDRATOR,5 433280
999
STRAP SERVICE BRAKE AIR RESERVOIR
999
SPACER TUBE BATTERY BASE FRAME TO BATTERY/APPARATUS SUPPORT
999
WASHER , Replaced By: A3609902340
999
WASHER BRACKET TO LEFT SIDE MEMBER
999
BRACKET COMPRESSED AIR LINES, Replaced By: A6205240340
999
FITTING AIR RESERVOIR,CONNECTION: "15",5 433280
999
RESERVOIR5.6L,114,3 MM,10 BAR
999
T-FITTING REAR AXLE REGULATING SOLENOID VALVE, CONNECTIONS: "21,22"
999
FITTING REAR AXLE REGULATING SOLENOID VALVE, CONNECTIONS: "10"
