Поз.
Артикул
Описание
5
STEERING SUPPORT
5
STEERING SUPPORT AT FRAME
5
STEERING SUPPORT AT FRAME
5
STEERING SUPPORT
8
SCREW STEERING SUPPORT TO FRAME
8
NUT CONSOLE TO SUPPORT
8
SCREW STEERING SUPPORT TO FRAME M 14X50
8
SCREW STEERING SUPPORT TO FRAME M 14X55
11
NUT STEERING SUPPORT TO FRAME
11
NUT , Replaced By: N910113014000
14
SCREW , Replaced By: N308676016006
14
SCREW BRACKET TO REAR AXLE M 20X1.5X45
14
FITTED SCREW STEERING BRACKET TO FRAME
14
SCREW STEERING BOX ASSEMBLY TO STEERING SUPPORT
17
PITMAN ARM AT STEERING GEAR,K 072178
17
PITMAN ARM ,5 158233
20
NUT PITMAN ARM TO STEERING BOX ASSEMBLY
23
DRAG LINKLEMFOERDER,5 158233K 218235
23
DRAG LINKEHRENREICH,5 158233K 218235
23
DRAG LINKEHRENREICH
23
DRAG LINK ,K 072178
23
DRAG LINK ,K 072178
23
DRAG LINKLEMFOERDER
23
DRAG LINKLEMFOERDER,5 158233K 218235
23
DRAG LINKEHRENREICH,5 158233K 218235
26
BOOT DRAG LINK
29
DRAG LINK ENDLEMFOERDER
29
DRAG LINK ENDEHRENREICH
29
DRAG LINK END R.H. THREAD EHRENREICH
32
BOOT DRAG LINK
35
CLAMP DRAG LINK END TO DRAG LINK EHRENREICH
35
CLAMP DRAG LINK END TO DRAG LINK LEMFOERDER
38
HEXAGON HEAD BOLT. SCREW CLAMP TO DRAG LINK
38
SCREW , Replaced By: N308676012017
41
NUT , Replaced By: N910113012003
41
HEXAGON NUT EXHAUST PIPE TO BRACKET ON SIDE MEMBER
43
NUT DRAG LINK TO LEVER
43
NUT DRAG LINK END M 24X1.5
44
NUT DRAG LINK TO LEVER
44
NUT , Replaced By: N000937024002
47
COTTER PIN DRAG LINK TO LEVER
