Поз.
Артикул
Описание
5
REAR SPRING (SUPPORTING SPRING),3 LEAVES
5
REAR SPRING , FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO. 5 393360, Replaced By: A6753202906
8
BUSHING SPRING EYE,FRONT AND REAR
11
SHIM BETWEEN THE SPRING LEAVES, TO BE ADAPTED DURING ASSEMBLY
11
SHIM , Replaced By: A9703210184
11
SHIM , Replaced By: A9703210184
14
SHIM BETWEEN THE SPRING LEAVES
17
RUBBER BUFFER BETWEEN THE SPRING EYES
32
RUBBER BUFFER
35
SPRING BOLTM 12X110
38
HEXAGON NUT. NUT SPRING BOLT
38
NUT , Replaced By: N910113012005
41
SPRING CLAMP , Replaced By: A6763210033
41
SPRING CLAMP AT SPRING LEAF NO.5
56
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
56
NUT , Replaced By: N913004008001
74
THRUST WASHER REAR SPRING TO REAR SPRING FRONT BRACKET
77
SHACKLE (SPRING SHACKLE)
80
BUSHING SPARE WHEEL HOIST TO CROSS MEMBER
80
BUSHING REAR SPRING TO REAR SPRING REAR BRACKET
83
SCREW VIBRATION ABSORBER TO CONSOLE
83
SCREW , Replaced By: N000960018072
86
NUT , Replaced By: N910113018004
86
NUT INTERMEDIATE LEVER TO STEERING SUPPORT
95
SHIM
101
PLATE REAR SPRING TO REAR AXLE
104
U-BOLT REAR SPRING TO REAR AXLE 320 MM
107
WASHER FRONT SPRINGS TO FRONT AXLE
110
NUT FRONT SPRINGS WITH TORSION BAR TO FRONT AXLE
113
BRACKET , TO BE ADAPTED DURING ASSEMBLY, Replaced By: A6733200243
113
BRACKET AXLE STOP
116
HELPER SPRING RUBBER BUFFER
119
PIN RUBBER BUFFER
122
SCREW BRACKET TO SIDE MEMBER
122
SCREW , Replaced By: N304017010002
125
SHIM , FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO. 5 532118, Replaced By: A6753250484
125
SHIM BRACKET TO SIDE MEMBER, TO BE ADAPTED DURING ASSEMBLY
128
NUT STRAP TO BRACKET
128
NUT , Replaced By: N910113010000
