Поз.
Артикул
Описание
11
RESERVOIR , Replaced By: A0014328901
11
RESERVOIR5/25L
11
RESERVOIR5/25L
17
SUPPORT AIR RESERVOIR TO FRAME
20
BASE SUPPORT TO FRAME
23
SCREW CONSOLE TO SIDE MEMBER
23
SCREW , Replaced By: N308676012026
26
WASHER BRACKET TO FRAME
35
STRAP ,K 093236
38
SCREW END PIECE TO EXHAUST PIPE M 10X25
41
NUT , Replaced By: N910113010000
41
NUT STRAP TO BRACKET
50
SUPPORT AIR RESERVOIR
50
SUPPORT ,5 914743K 205704
53
T-FITTING OVERFLOW VALVE,CONNECTION: "12"
65
FITTING AIR RESERVOIR,CONNECTION: "11"
66
FITTING LOAD/NO-LOAD VALVE,CONNECTION: "20",5 727400
66
FITTING REAR AXLE REGULATING SOLENOID VALVE, CONNECTIONS: "10"
66
FITTING REAR AXLE REGULATING SOLENOID VALVE, CONNECTIONS: "10"
68
HOLLOW SCREW FITTING LEFT AND RIGHT COMBINATION CYLINDERS, CONNECTION: "11,12",5 356525
69
HOLLOW SCREW FRONT AXLE REGULATING SOLENOID VALVE, CONNECTION: "10",K 009079
70
HOLLOW SCREW FOUR-CIRCUIT PROTECTIVE VALVE, CONNECTION: "24"
71
NUT CHECK VALVE TO AIR RESERVOIR
74
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940203
74
THRUST RING CHECK VALVE TO AIR RESERVOIR
77
O-RING CHECK VALVE TO AIR RESERVOIR
83
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
83
SEAL RING LOAD/NO-LOAD VALVE,CONNECTIONS: "20,21",5 727400
92
SEALING RING. SEAL RING DELIVERY LINE TO STEERING
95
VALVE DRAIN, Replaced By: A0004322107
95
VALVE DRAIN, Replaced By: A0004322107
95
VALVE DRAIN, Replaced By: A0004322407
95
VALVE. DRAIN VALVE DRAIN
95
VALVE. DRAIN VALVE DRAIN
104
SEAL RING AIR RESERVOIR,CONNECTIONS: "24,34"
107
VALVE , Replaced By: A0044293244
107
VALVE , Replaced By: A0044293144
116
VALVE
119
DIAPHRAGM
122
REPAIR KIT OVERFLOW VALVE TO 003 429 09 44,WABCO
123
FITTING LINE CONNECTION
125
ELBOW FITTING , Replaced By: A0004294638
125
ELBOW FITTING COMBINATION CYLINDER,CONNECTION: "12"
128
FITTING REAR AXLE REGULATING SOLENOID VALVE, CONNECTIONS: "10"
128
FITTING AIR RESERVOIR,CONNECTION: "11"
131
HOLLOW SCREW FRONT AXLE REGULATING SOLENOID VALVE, CONNECTION: "10",K 009079
134
NUT CHECK VALVE TO AIR RESERVOIR
137
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940203
137
THRUST RING CHECK VALVE TO AIR RESERVOIR
140
O-RING CHECK VALVE TO AIR RESERVOIR
143
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
146
SEAL RING AIR RESERVOIR,CONNECTIONS: "24,34"
149
SCREW. UNION SCREW LINE CONNECTION
999
NUT , Replaced By: N913004008001
999
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
999
SCREW PIPE CLAMP
999
WASHER BRACKET TO LEFT SIDE MEMBER
999
WASHER , Replaced By: N009021008213
999
WASHER UNDERRUN PROTECTION AND BRACKET TO FRAME
999
WASHER , Replaced By: N006902011102
999
SCREW , Replaced By: N304017008021
999
SCREW , Replaced By: N304017008021
999
WASHER EXHAUST MUFFLER TO STRAP
999
WASHER , Replaced By: N000125008443
999
BRACKET AIR RESERVOIR
999
SUPPORT (PROTECTION AGAINST TORSION)
999
WASHER , Replaced By: N006902011100
999
BASE AIR RESERVOIR TO RIGHT SIDE MEMBER, INSIDE
999
STRAP AIR RESERVOIR
999
FITTING AIR RESERVOIR,CONNECTION: "26", NOT USED
999
T-FITTING LINE CONNECTION
999
BANJO UNION BRAKE POWER REGULATOR W/RELAY VALVE, CONNECTION: "40"
999
SCREW. UNION SCREW LINE CONNECTION
999
SCREW. UNION SCREW , Replaced By: A0009973734
