Поз.
Артикул
Описание
34
HOSE LEAK LINE 4X6 MM, ORDER BY THE METER
34
PLASTIC PIPE RISING PIPE 4X6 MM
44
FITTING (PARTS KIT),LINE RUPTURE,5 909352K 169122
47
LOCK , Replaced By: A0009945448
47
LOCK LINE CONNECTION
50
REPAIR KIT COMPRESSED-AIR-LINE PLUG-CONNECTION TO M 16
50
REPAIR KIT , Replaced By: A0309971748
54
BANJO UNION HOSE WIDTH, / I.D., 4/12 MM
64
ELBOW FITTING COMPRESSED-AIR-LINE PLUG-CONNECTION TO M 16
74
DISTRIBUTOR HOSE WIDTH, 6 MM
84
CONNECTOR LINE MOUNTING
114
SCREW. UNION SCREW LINE CONNECTION
114
SCREW. UNION SCREW , Replaced By: A0009973734
124
SEAL RING COMPRESSED-AIR-LINE PLUG-CONNECTION
134
CONNECTOR COMPRESSED-AIR-LINE PLUG-CONNECTION
134
CONNECTOR , Replaced By: A0029905378
164
VALVE , Replaced By: A0044293144
174
VALVE (OVERFLOW VALVE) GRAU
174
VALVE , Replaced By: A0044293244
184
VALVE , Replaced By: A0044293144
184
VALVE (OVERFLOW VALVE) WABCO
194
DIAPHRAGM
204
VALVE
214
REPAIR KITTO 001 429 52 44
224
REPAIR KITBOSCH
244
BRACKET OVERFLOW VALVE,CONNECTION: "20"
244
BRACKET OVERFLOW VALVE,CONNECTION: "10"
254
SCREW COVER PLATE TO COVER PLATE M 6 X 12
254
SCREW , Replaced By: N304017006018
264
LOCK WASHER CONTROL LEVER TO INJECTION PUMP LEVER
274
FITTING AIR RESERVOIR,CONNECTIONS: "10,20"
284
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940203
284
THRUST RING CHECK VALVE TO AIR RESERVOIR
294
O-RING CHECK VALVE TO AIR RESERVOIR
304
HOLLOW SCREW HEATING CONNECTION
314
SEAL RING LINE CONNECTION
324
LOOM TIE LINE MOUNTING 280 MM
999
DIAPHRAGM , Replaced By: A0004290745
999
CONNECTOR COMPRESSED-AIR-LINE PLUG-CONNECTION
999
CONNECTOR COMPRESSED-AIR-LINE PLUG-CONNECTION
999
SEAL RING , Replaced By: A0009940747
999
LOCK RING LINE CONNECTION
999
SEALING CORD COMPRESSED-AIR-LINE PLUG-CONNECTION
999
T-FITTING EXHAUST BRAKE LINE CONNECTION
999
COUPLING COMPRESSED-AIR-LINE PLUG-CONNECTION
999
PLUG COMPRESSED-AIR-LINE PLUG-CONNECTION
999
PLASTIC PIPE. HOSE AERATION 6X8 MM, ORDER BY THE METER
999
CONNECTOR DISTRIBUTOR TO CAB
999
PLUG BLEEDING,D 013038
999
SCREW , Replaced By: N304017006034
999
SCREW COVER PLATE TO COVER PLATE M 6 X 10
