Поз.
Артикул
Описание
5
EXHAUST PIPE CONNECTING PIPE TO EXHAUST MANIFOLD,5 337342
5
EXHAUST PIPE CONNECTING PIPE TO EXHAUST MANIFOLD,5 528483K 049383
5
EXHAUST PIPE CONNECTING PIPE TO EXHAUST MANIFOLD,K 049384
5
EXHAUST PIPE , FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO.5 180543, Replaced By: A6764901019
5
EXHAUST PIPE CONNECTING PIPE TO EXHAUST MANIFOLD,5 3373435 528482
8
SCREW LEFT AND RIGHT CONSOLES TO CAB
8
SCREW , Replaced By: N308676012015
11
NUT , Replaced By: N910113012006
11
NUT THROTTLE HOUSING AND BRACKET TO FRONT EXHAUST PIPE
14
PROTECTIVE PLATE FRONT EXHAUST PIPE,5 502998
14
PROTECTIVE PLATE , FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO. 5 422640, Replaced By: A6764900730, +001A6764901140, +002A1089900340, +002N000933008147, +002N913004008004
17
BRACKET HEAT SHIELD,5 502998
17
BRACKET , Replaced By: A6764901140
20
SCREW EXHAUST PIPE TO BRACKET
23
WASHER PROTECTIVE PLATE TO BRACKET,5 502998
26
NUT , Replaced By: N913004008001
26
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
29
BRACKET FRONT EXHAUST PIPE,5 337342
32
BRACKET , FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO. 5 422640
32
BRACKET FRONT EXHAUST PIPE TO BRACKET,5 5029985 528482
35
BRACKET FRONT EXHAUST PIPE,5 528483
41
SCREW BRACKET TO CAB CONSOLE M14X1.5X40
41
SCREW BRACKET TO FRAME SIDE MEMBER
44
NUT , Replaced By: N910113014001
44
NUT BRACKET TO SIDE MEMBER
47
CLAMP INTERMEDIATE PIPE TO PARTICLE FILTER
47
CLAMP , Replaced By: N071555090502
50
SCREW BRACKET TO SIDE MEMBER
50
SCREW , Replaced By: N304017010002
53
NUT EXHAUST PIPE TO SIDE MEMBER
56
FLEXIBLE METAL TUBE FRONT EXHAUST PIPE TO MUFFLER,K 165446
59
CLAMP EXHAUST PIPE TO MUFFLER
59
CLAMP EXHAUST PIPE TO MUFFLER
62
SCREW BRACKET TO EXHAUST PIPE,5 528482
62
SCREW BRACKET TO EXHAUST PIPE,5 528482
65
WASHER , Replaced By: N000125008443
65
WASHER EXHAUST MUFFLER TO STRAP
65
WASHER EXHAUST MUFFLER TO STRAP
68
NUT , Replaced By: N913004008001
68
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
68
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
71
EXHAUST MUFFLER
71
EXHAUST MUFFLER , Replaced By: A6764900501
173
REAR EXHAUST PIPE ,5 743553-5 8000005 803730
173
REAR EXHAUST PIPE (TAIL PIPE),5 1522775 337342
173
REAR EXHAUST PIPE (TAIL PIPE)
173
REAR EXHAUST PIPE ,5 7435535 803730, Replaced By: A6764928004
173
REAR EXHAUST PIPE , EXHAUST STOCK OF OLD PARTS UP TO 5 185299, Replaced By: A6764920904
179
CLAMP BRACKET TO EXHAUST PIPE
182
HEXAGON HEAD BOLT. SCREW EXHAUST PIPE TO MUFFLER
182
SCREW , Replaced By: N304014008021
185
WASHER EXHAUST MUFFLER TO STRAP
185
WASHER , Replaced By: N000125008443
188
NUT , Replaced By: N913004008001
188
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
191
BRACKET EXHAUST PIPE SUSPENSION,5 743553-5 8000005 803730
197
SCREW , Replaced By: N304017008034
197
SCREW BRACKET TO CROSS CONNECTION STRUT
200
WASHER SUPPORTING RAIL TO SUPPORT,5 429712
203
NUT , Replaced By: N913004008001
203
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
203
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
209
SCREWM 8X40
212
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
212
NUT , Replaced By: N913004008001
218
CLAMP , Replaced By: N071555090502
218
CLAMP INTERMEDIATE PIPE TO PARTICLE FILTER
221
SCREW BRACKET TO SIDE MEMBER
221
SCREW , Replaced By: N304017010002
224
NUT EXHAUST PIPE TO SIDE MEMBER
999
SCREW PROTECTIVE PLATE TO CLAMP
999
SCREW COVERING TO SUPPORT
999
BRACKET AIR INTAKE PIPE,5 551665 TO BE ADAPTED DURING ASSEMBLY
999
RUBBER BUFFER EXHAUST PIPE REAR ON BATTERY CASE
999
BRACKET FUEL LINES TO TRANSMISSION
999
PROTECTIVE PLATE , NOT USED
999
SUPPORT EXHAUST MUFFLER TO BRACKET
999
WASHER , Replaced By: N006902011100
999
BRACKET , EXHAUST STOCK OF OLD PART NUMBERS FIRST UP TO IDENT NO. K 139807, Replaced By: A6744924841
999
BRACKET EXHAUST PIPE REAR ON BATTERY CASE
999
BRACKET , Replaced By: A3524920141
999
BRACKET EXHAUST MUFFLER TO BRACKET
999
BRACKET , EXHAUST STOCK OF OLD PARTS UP TO IDENT NO. K 227991, Replaced By: A6764902640
999
BRACKET HEAT SHIELD
999
BRACKET BRACKET TO FILTER BRACKET
999
SCREW , Replaced By: N304017008021
999
WASHER , Replaced By: N006902011102
999
WASHER UNDERRUN PROTECTION AND BRACKET TO FRAME
999
WASHER HEAT SHIELD TO BRACKET
999
SCREW PIPE CLAMP
999
NUT STRAP TO BRACKET
999
NUT , Replaced By: N910113010000
