Поз.
Артикул
Описание
5
REAR SPRING 11-LEAF,WITH 8-LEAF HELPER SPRING
5
REAR SPRING 9-LEAF,WITH 7-LEAF HELPER SPRING
8
SPRING LEAFNO.1,TO 384 320 87 08
8
SPRING LEAFNO.1,TO 376 320 80 08
11
BUSHING
11
BUSHING
14
SPRING LEAFNO.2,TO 384 320 87 08
14
SPRING LEAFNO.2,TO 376 320 80 08
17
SPRING LEAFNO.3,TO 384 320 87 08
17
SPRING LEAFNO.3,TO 376 320 80 08
20
SPRING LEAFNO.4,TO 384 320 87 08
20
SPRING LEAFNO.4,TO 376 320 80 08
29
SPRING LEAFNO.7,TO 384 320 87 08
32
SPRING LEAFNO.8,TO 376 320 80 08
41
SPRING LEAF HELPER SPRING NO.1,TO 384 320 87 08
41
SPRING LEAF HELPER SPRING NO.1,TO 376 320 80 08
47
SPRING LEAF HELPER SPRING NO.3,TO 384 320 87 08
56
SPRING LEAF HELPER SPRING NO.6,TO 376 320 80 08
62
SPRING BOLT LEAF SPRING M 12X245MM
65
NUT BRACKET TO SIDE MEMBER
71
SPACER
71
SPACER20 MM
77
SPACER TUBE SPRING CLAMP
80
SCREW
83
NUT BRACKET TO SIDE MEMBER,XB209706
85
SHACKLE REAR-SPRING REAR BRACKET
88
BUSHING
88
BUSHING
91
SHACKLE PIN REAR SPRING TO SPRING SHACKLE AND TO SPRING FRONT AND REAR BRACKETS
94
GREASE NIPPLE PROTECTIVE TUBE
97
WASHER AS REQUIRED 4.0 MM
97
WASHER FRONT SPRING TO SPRING SHACKLE & SPRING BRACKETS
97
WASHER AS REQUIRED 4.2 MM
97
WASHER SHACKLE PIN, AS REQUIRED 4.0 MM
100
SEAL RING SPRING SHACKLE TO SPRING REAR BRACKET
103
BOLT SPRING SHACKLE TO SPRING REAR BRACKET
106
WASHER GROUND CABLE
109
NUT BRACKET TO SIDE MEMBER,XB209706
112
PLATE REAR SPRING TO REAR AXLE
112
PLATE , Replaced By: A6953257031
115
U-BOLT , THE OLD PART MUST NO LONGER BE INSTALLED IN THIS PLACE ONLY REPLACEABLE BY PAIRS5 999999K 000001 - K 028584, Replaced By: A6793510825, +001A6793250031
115
U-BOLT REAR SPRING TO REAR AXLE 400 MM
118
SPACER FRONT SPRINGS TO FRONT AXLE
121
DOWEL PIN (CENTERING CONE)
124
WASHER FRONT SPRINGS TO FRONT AXLE
127
NUT TORSION BAR TO BEARING BRACKET,5 904661
