Поз.
Артикул
Описание
4
TUBE FROM HIGH PRESSURE HOSE TO STEERING, LENGTH AVAILABLE: 3000 MM
6
LINE FROM VALVE TO CONNECTION FITTING,K 172343 ORDER BY THE METER
8
LINE BRAKES 6X0.7 MM, LENGTH AVAILABLE 25000 MM
8
LINE , Replaced By: A0004296201
11
PLASTIC PIPE FUEL LINE 12X1,5 MM, ORDER BY THE METER
11
HOSE , Replaced By: A0009872827
14
SLEEVE LINE CONNECTION
14
BUSHING , Replaced By: N915062009000
17
PLASTIC PIPE. HOSE AERATION 6X8 MM, ORDER BY THE METER
21
SLEEVE LINE CONNECTION
21
SLEEVE , Replaced By: N915062006000
22
LOOM TIE LINE MOUNTING 280 MM
35
VALVE TWO-CIRCUIT, PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
38
VALVE DISC101
38
VALVE DISC024, FROM CHASSIS 674068 ALSO INSTALLED ON, 500001-599999,673550,673631,673890,673916-673918,673922,673927
41
SEALBOSCH 024, FROM CHASSIS 674068 ALSO INSTALLED ON, 500001-599999,673550,673631,673890,673916-673918,673922,673927
44
CUP101
44
CUP , Replaced By: A0014312386
44
CUP , INCLUDED IN RANGE OF DELIVERY OF 000 431 68 06
45
GASKETTO 000 429 16 30
47
PROTECTIVE CAP101
49
SPRING , Replaced By: A0009935205
51
SEAL RING101
53
CUP , INCLUDED IN RANGE OF DELIVERY OF 000 431 68 06
56
SEAL RING LINE CONNECTION
59
DOUBLE FITTING BETWEEN THE LINES, BUTT CONNECTION
62
FITTING SHUTTLE VALVE,CONNECTION: "20"
62
FITTING , Replaced By: A0019972372
68
ELBOW FITTING CHECK VALVE TO AIR RESERVOIR
71
O-RING CHECK VALVE TO AIR RESERVOIR
74
THRUST RING CHECK VALVE TO AIR RESERVOIR
74
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940203
77
NUT CHECK VALVE TO AIR RESERVOIR
80
RESERVOIR COMPRESSED AIR
80
RESERVOIR COMPRESSED AIR 20 L
83
VALVE DRAIN, Replaced By: A0004322107
83
VALVE. DRAIN VALVE DRAIN
83
VALVE. DRAIN VALVE DRAIN
83
VALVE DRAIN, Replaced By: A0004322107
83
VALVE DRAIN, Replaced By: A0004322407
83
VALVE , Replaced By: A0004320807
86
RING , Replaced By: A0005830296
103
SEAL RING LINE CONNECTION
106
FITTING FRONT AXLE REGULATING SOLENOID VALVE, CONNECTION: "20"
106
FITTING FRONT AXLE REGULATING SOLENOID VALVE, CONNECTION: "20", Replaced By: N000000006191
110
T-FITTING AT BRAKE BOOSTER,5 062721
114
ELBOW FITTING DELIVERY LINE TO PUMP
114
FITTING , Replaced By: A0019902771
118
SCREW PLUG LOAD/NO-LOAD VALVE,CONNECTION: "21"
118
SCREW PLUG , Replaced By: N000908022011
121
T-FITTING
125
O-RING CHECK VALVE TO AIR RESERVOIR
128
THRUST RING CHECK VALVE TO AIR RESERVOIR
128
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940203
132
NUT CHECK VALVE TO AIR RESERVOIR
135
SEAL RING FUEL LINE TO FEED PUMP
138
SCREW PLUGTO 000 553 03 05,000 553 18 05,
138
SCREW PLUG , Replaced By: N000908014009
142
SCREW PLUG FUEL TANK
142
SCREW PLUG , Replaced By: N007604014110
145
ELBOW FITTING 3/2-WAY VALVE,CONNECTION "1"
145
ELBOW FITTING , Replaced By: A0019907571
148
SEAL RING FROM 3/2-WAY VALVE TO QUICK BREATHER VALVE,5 431227
151
THRUST RING FROM 3/2-WAY VALVE TO QUICK BREATHER VALVE,5 431227
153
NUT FROM 3/2-WAY VALVE TO QUICK BREATHER VALVE,5 431227
196
BRACKET OIL LINE MOUNTING
197
SCREW PIPE CLAMP
197
SCREW , Replaced By: N304017008021
198
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
199
NUT
202
CLAMP DELIVERY AND SUCTION LINES TO STEERING
202
CLAMP , Replaced By: A6739950001
205
SCREW PROTECTION PLATE TO BRACKET
208
LOCK WASHER CONTROL LEVER TO INJECTION PUMP LEVER
211
NUT BALL PIVOT TO LEVER
999
LINE , Replaced By: A0005516256
999
SPACER RING AT BRAKE BOOSTER
999
THREADED UNION BRAKE CYLINDER
999
SEAL RING
999
SEAL RING , Replaced By: A0179974148
999
BRACKET POS. CABLE,XB209706
999
ROD , Replaced By: A3522420237
999
RODTO 352 240 02 25
999
ELBOW FITTING LOAD/NO-LOAD VALVE, 620.415 UP TO CHASSIS 5 014668 620.416 UP TO CHASSIS 5 000515 620.417 UP TO CHASSIS 4 972023
999
LEVER BRAKE BOOSTER TO BRACKET
999
YOKE
999
BRACKET , Replaced By: A3604300910
999
CLAMP LINE MOUNTING
999
FITTING , Replaced By: A0029971172
