Поз.
Артикул
Описание
5
5
5
5
RADIATOR , Replaced By: A9015003300
8
FILLER CAP. RADIATOR CAP
8
RADIATOR CAP
11
HOSE
14
SCREW WATER DRAIN
14
SCREW COOLING WATER DRAIN
17
SWITCH,AUTOMATIC EXPANSION TANK, A 328810 EXCEPT CODE 807 ALSO INSTALLED IN VEHICLE FROM A 328811 WITH CODE 806
19
PIN BUSHING HOUSING BIPOLAR
21
ROUND PIN BUSHING4 MM2
23
23
25
CLIP-TYPE NUT FAN SHROUD TO RADIATOR
27
COVERING RIGHT
27
COVERING , Replaced By: A9015050888
29
COVERING LEFT
32
SCREW LICENSE PLATE TO BRACKET
35
WASHER COMPRESSED AIR LINE TO BRACKET
35
WASHER COVERING TO CAB
38
LOCK COVERING,LEFT,ON RADIATOR
38
NUT RETAINER
44
COVERING BOTTOM
47
SHEET METAL SCREW
47
SHEET METAL SCREW , Replaced By: N000000000453
47
COMBINATION BOLT , Replaced By: N007981004244, +001N000125004311
47
SHEET METAL SCREW MODULE TO HOUSING
53
LOCK COVERING,BELOW,ON RADIATOR
53
LOCK. SHEET METAL NUT PLATE TO FRAME,V 202043
56
COVERING TOP
59
SHEET METAL SCREW , Replaced By: N000000000523
59
SHEET METAL SCREW COVERING TO CAB 4.2X19
62
LOCK. SHEET METAL NUT PLATE TO FRAME,V 202043
62
LOCK COVERING,BELOW,ON RADIATOR
65
RUBBER MOUNTING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A6385040212
68
RUBBER MOUNTING RADIATOR MOUNTING,TOP
71
CLAMP RADIATOR MOUNTING,TOP
74
HOSE TOP
74
77
80
LOOM TIE. CLAMP HOSE FASTENING
80
LOOM TIE. CLAMP BRAKE HOSE 45-55 MM, DISCONTINUED,PART IS NO LONGER REQUIRED
80
CLAMP , Replaced By: A0069974390
80
CLAMP , Replaced By: A0069970690
83
HOSE DE-AERATION LINE, LENGTH AVAILABLE: 1000 MM
86
HOSE CLAMP LINE MOUNTING
86
CLAMP , Replaced By: A0059970190
86
CLAMP , Replaced By: A1409950036
89
92
95
CLAMP CABLE HARNESS MOUNTING
95
CLAMP , Replaced By: N916016010211
95
CLAMP , Replaced By: N000000001045
98
SCREW PUMP TO BRACKET
101
NUT SPRING-LOADED PUSH ROD
