Поз.
Артикул
Описание
103
PULLEY AT AIR COMPRESSOR
103
PULLEY AIR COMPRESSOR
110
NUT VIBRATION ABSORBER TO CONSOLE
113
WASHER PULLEY TO AIR COMPRESSOR, FROM ENGINE 238226 YEAR OF MANUFACTURE 1992
117
LOCK WASHER BELL HOUSING TO TRANSMISSION
124
BRACKET BELT TENSION READJUSTMENT
131
SUPPORT TIGHTENER PULLEY
131
SUPPORT TIGHTENER PULLEY
145
CLAMPING PIECE
152
CLAMPING PIECE TIGHTENER PULLEY
152
CLAMPING PIECE , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A3141550228
159
NUT TIGHTENER PULLEY TO LEVER
166
HEXAGON HEAD BOLT. SCREW BRACKET TO SIDE MEMBER M12X45
166
HEXAGON HEAD BOLT BEARING BRACKET TO SIDE MEMBER M 12X50
166
SCREW BRACKET TO FRAME
173
HEXAGON HEAD BOLT. SCREW TIGHTENER PULLEY SUPPORT AND BRACKET TO FUEL-FILTER/AIR-COMPRESSOR SUPPORT, UP TO ENGINE 238225 YEAR OF MANUFACTURE 1992
180
HEXAGON HEAD BOLT. SCREW FRONT EXHAUST PIPE TO BRACKET
187
WASHER MOUNTING USED FOR FRAME CONNECTION PARTS
187
WASHER COVER PLATE TO FRAME
194
TIGHTENER PULLEY
201
BALL BEARING
201
BALL BEARING TIGHTENER PULLEY
208
LOCK RING52X2 MM
208
LOCK RING
236
SCREW PIPE ELBOW TO CHARGING AIR INTERCOOLER M 10X35,5 708090
250
CAP
