Поз.
Артикул
Описание
6
AIR CLEANER ,086792
56
BOOT PIPE ELBOW TO TURBOCHARGER
68
HOSE (ACCORDION TUBE) FROM AIR INTAKE PIPE TO INTAKE FITTING
71
CLAMP , Replaced By: N000000000678
71
CLAMP HOSE TO AIR CLEANER AND CAB CONSOLE 130-150X13 MM, Replaced By: N000000005892
71
CLAMP HOSE TO CAB CONSOLE AND TO ENGINE CONNECTION
77
PROTECTIVE PLATE
80
SCREW COVER PLATE TO BRACKET
83
WASHER COMPRESSED AIR LINE TO BRACKET
83
WASHER , Replaced By: N009021006208
86
NUT PUMP TO BRACKET
86
NUT , Replaced By: N913004006001
107
CLAMP
107
CLAMP LINE MOUNTING
107
CLAMP , Replaced By: N000000000670
107
CLAMP INTERMEDIATE PIPE TO PARTICLE FILTER
107
CLAMP25-40X13 MM
999
AIR INTAKE PIPE FROM AIR CLEANER TO INTAKE PIPE,086793
999
AIR INTAKE CASE ,086793
