Поз.
Артикул
Описание
6
EXPANSION PLUG
7
GROMMET
18
SUPPORT RADIATOR AND EXPANSION TANK
18
SUPPORTING FRAME RADIATOR AND EXPANSION TANK
18
SUPPORTING FRAME RADIATOR AND EXPANSION TANK
20
SUPPORT RADIATOR AND EXPANSION TANK
26
SCREW
32
PIN
38
COTTER PIN SHIFT LEVER TO CASE
40
ANGLE
42
ANGLE
47
SUPPORT
47
SUPPORT
53
HEXAGON HEAD BOLT. SCREW BRACKET TO SIDE MEMBER M10X25
56
NUT EXHAUST PIPE AND PIPE CLAMP TO BRACKET
56
NUT , Replaced By: N913023010002
59
NUT BRACKET TO SIDE MEMBER M12X1.5
59
HEXAGON NUT. NUT BRACKET TO SIDE MEMBER M 12X1,5
62
SCREW BRACKET TO SIDE MEMBER M10X35
62
HEXAGON HEAD BOLT. SCREW BRACKET TO SIDE MEMBER M10X25
62
HEXAGON HEAD BOLT. SCREW BRACKET TO SIDE MEMBERM 12X1.5X30
62
HEXAGON HEAD BOLT BRACKET TO SIDE MEMBER M12X1.5X40
62
HEXAGON HEAD BOLT BRACKET TO SIDE MEMBER M12X1.5X35
62
HEXAGON HEAD BOLT BEARING BRACKET TO SIDE MEMBER M 12X50
62
HEXAGON HEAD BOLT
65
NUT , Replaced By: N913023006001
65
NUT BRACKET TO SIDE MEMBER M12X1.5
86
TANK EXPANSION TANK,D 247423
86
TANK EXPANSION TANK
86
EXPANSION RESERVOIR EXPANSION TANK
89
SENSOR. CONTROL UNIT COOLING WATER EXPANSION
89
SENDER UNIT COOLING WATER LEVEL SENDER UNIT
92
SEAL RING SENDER UNIT TO COOLING WATER EXPANSION TANK
93
RADIATOR CAP
96
RADIATOR CAP ,D 247423
101
CLAMP EXPANSION TANK TO SUPPORT
104
HEXAGON HEAD BOLT RESONATOR TO TRANSMISSION CASE,K 138633
110
BASE STRAP
113
COTTER PIN STRAP TO BRACKET
116
NUT BRACKET TO FIRE WALL
