Поз.
Артикул
Описание
50
LU HOSE LINE FROM TRANSMISSION TO OIL COOLER 690 MM
60
LU HOSE LINE FROM OIL COOLER TO TRANSMISSION 1360 MM
60
HOSE ASSEMBLY FROM OIL COOLER TO TRANSMISSION 840 MM
70
LU HOSE LINE FROM TRANSMISSION TO OIL COOLER 1130 MM
100
FITTING FROM OIL COOLER TO TRANSMISSION
170
LINE FROM OIL COOLER TO TRANSMISSION 2768 MM
180
LINE FROM OIL COOLER TO TRANSMISSION 2650MM
200
LINE FROM OIL COOLER TO TRANSMISSION
210
LINE FROM OIL COOLER TO TRANSMISSION
220
LINE FROM TRANSMISSION TO OIL COOLER
230
LINE FROM TRANSMISSION TO OIL COOLER
250
BRACKET PIPE LINE FIXTURE
250
BRACKET PIPE LINE FIXTURE
260
BRACKET WITH PRESSURE REGULATOR
270
HEXAGON HEAD BOLT BRACKET TO SIDE MEMBER M12X1.5X35
280
PRESSURE CONTROL VALVE WITH PRESSURE REGULATOR
283
SCREW-IN FITTING
290
BOLT AND WASHER ASSY.
295
SHIM
300
HEXAGON HEAD BOLT. SCREW BRACKET TO SIDE MEMBERM 12X1.5X30
300
HEXAGON HEAD BOLT RESONATOR TO TRANSMISSION CASE,K 138633
310
NUT EXHAUST PIPE AND PIPE CLAMP TO BRACKET
310
NUT BRACKET TO SIDE MEMBER M12X1.5
330
CLAMP DELIVERY AND SUCTION LINES TO ENGINE, FRONT
330
CLAMP , Replaced By: A3829950701
340
HEXALOBULAR BOLT AIR CLEANER TO BRACKET
340
HEXALOBULAR BOLT WIRE CABLE TO BRACKET
350
NUT BRACKET TO FIRE WALL
350
NUT HORN TO BRACKET M8
360
PLASTIC PIPE8X6 MM, ORDER BY THE METER
370
ELBOW FITTING , Replaced By: A0049905371
380
CONNECTOR , Replaced By: A0029905478
390
INSULATING HOSE
420
PLUG BELL HOUSING
425
PLUG TO PLUG THE BORES
430
CABLE HARNESS VOITH RETARDER
500
PLUG SOCKET. PLUG HOUSING
503
PLUG SOCKET 4-POLE
506
PLUG HOUSING , Replaced By: A0055404081
509
WIRE SEAL GREY 0.5-1.0 MM2
512
ROUND PIN BUSHING
515
BOOT 90 DEGREE OUTLET FOR CORRUGATED TUBE NW 8.5 GGVS
518
GASKET
521
THRUST RING(1.5MM) 0.5-1.0MM - TO A 368 540 03 08
524
BOOT 180 DEGREE OUTLET FOR CORRUGATED TUBE NW 8.5 GGVS
527
GASKET. BLIND PLUG
